| General Info | ||
|---|---|---|
| Model Number | AOC 24B2XDAM | AOC 25B3HM |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2020 | 2022 |
| Brand | AOC | AOC |
| Model Number | 24B2XDAM | 25B3HM |
| Display | ||
| Screen Size Class | 24" (inches) | 25" (inches) |
| Diagonal Size | 23.81 in 60.5 cm 604.7 mm 1.98 ft |
24.5 in 62.2 cm 622.3 mm 2.04 ft |
| Screen Width | 20.75 in 52.7 cm 527.04 mm 1.73 ft |
21.41 in 54.4 cm 543.744 mm 1.78 ft |
| Screen Height | 11.67 in 29.6 cm 296.46 mm 0.97 ft |
11.91 in 30.3 cm 302.616 mm 0.99 ft |
| Display Type | VA | VA |
| Display Bit Depth | 8 bits (6 bits + FRC) | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 16777216 | 16777216 |
| Bits | 24 | 24 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 1920 x 1080 | 1920 x 1080 |
| Screen Pixel Pitch | 0.275 mm | 0.28 mm |
| Screen Pixel Density | 92 ppi | 89 ppi |
| Screen-to-Body Ratio | 90.24 % | 90.5 % |
| Backlight Source | W-LED | W-LED |
| DCI P3 | 88% | |
| sRGB | 118 % | |
| NTSC 1953 | 96 % | |
| Screen Brightness | 250 cd/m² | 300 cd/m² |
| Static Screen Contrast | 3000 : 1 | 3500 : 1 |
| Dynamic Screen Contrast | 20000000 : 1 | 20000000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Display Minimum Response Time | 4 ms | 4 ms |
| Display Coating | Anti-glare/Matte (3H) | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 1.48 in 3.8 cm 37.6 mm 0.12 ft |
1.76 in 4.5 cm 44.8 mm 0.15 ft |
| Case Weight | 2.47 kg 5 lbs |
2.65 kg 6 lbs |
| Case Width with Stand | 21.24 in 53.9 cm 539.47 mm 1.77 ft |
21.94 in 55.7 cm 557.2 mm 1.83 ft |
| Case Height with Stand | 16.53 in 42 cm 419.8 mm 1.38 ft |
16.64 in 42.3 cm 422.6 mm 1.39 ft |
| Case Depth with Stand | 7.35 in 18.7 cm 186.8 mm 0.61 ft |
7.96 in 20.2 cm 202.3 mm 0.66 ft |
| Case Weight with Stand | 2.7 kg 6 lbs |
3.04 kg 7 lbs |
| Case Color | Black | Black |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x D-sub 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x DVI-D |
1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x D-sub |
| Audio | ||
| Audio Speakers | 2 x 2W | |
| Features | ||
| Cool Features | Flicker-free technology Low Blue Light Wide Viewing Angle 3-sided Frameless Design Adaptive-Sync technology |
Dynamic Colour Boost (DCB) technology Dynamic Contrast Ratio (DCR) technology HDR Mode Low Blue Light Flicker-free technology Clear Vision DDC2B (DDC/CI compatible) |
| Ergonomics | ||
| Case Width | 21.24 in 53.9 cm 539.47 mm 1.77 ft |
21.94 in 55.7 cm 557.2 mm 1.83 ft |
| Case Height | 12.64 in 32.1 cm 320.94 mm 1.05 ft |
12.85 in 32.6 cm 326.3 mm 1.07 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | No |
| Landscape or Portrait Pivot Support | No | No |
| Left or Right Swivel Support | No | No |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 5 ° | 5 ° |
| Backward Tilt | 20 ° | 23 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 50 Hz - 76 Hz | 48 Hz - 75 Hz |
| Horizontal Digital Frequency | 30 kHz - 83 kHz | 30 kHz - 85 kHz |
| Screen Interpolation Measurement Unit | NULL | NULL |
| Accessories | ||
| Extras | HDMI cable | HDMI cable |
| Certificates and Standards | ||
| Licenses | CE FCC Reach compliant RoHS |
CCC CE CECP CEL CH RoHS FCC Win11 |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
|
| Safe Operating Humidity Level | 10 % - 85 % | |
| Internal Storage Temperature | -25 °C - 55 °C -13 °F - 131 °F |
|
| Internal Storage Humidity | 5 % - 93 % | |
| Max Operating Altitude | 5000 | |
| Max Storage Altitude | 12192 |
| AOC 24B2XDAM | AOC 25B3HM |
