| General Info | ||
|---|---|---|
| Model Number | AOpen 20CH1Q | AOC E2070SWN |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2021 | 2013 |
| Brand | AOpen | AOC |
| Model Number | 20CH1Q | E2070SWN |
| Display | ||
| Screen Size Class | 20" (inches) | 20" (inches) |
| Diagonal Size | 19.45 in 49.4 cm 494 mm 1.62 ft |
19.45 in 49.4 cm 494 mm 1.62 ft |
| Screen Width | 17.09 in 43.4 cm 434 mm 1.42 ft |
17.08 in 43.4 cm 433.92 mm 1.42 ft |
| Screen Height | 9.28 in 23.6 cm 235.8 mm 0.77 ft |
9.3 in 23.6 cm 236.34 mm 0.78 ft |
| Display Type | TN | TN |
| Display Bit Depth | 8 bits (6 bits + FRC) | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 16777216 | 16777216 |
| Bits | 24 | 24 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 1366 x 768 | 1600 x 900 |
| Screen Pixel Pitch | 0.318 mm | 0.271 mm |
| Screen Pixel Density | 80 ppi | 93 ppi |
| Screen-to-Body Ratio | 78.79 % | |
| Backlight Source | W-LED | W-LED |
| NTSC 1953 | 72 % | 72 % |
| Screen Brightness | 200 cd/m² | 200 cd/m² |
| Static Screen Contrast | 600 : 1 | |
| Dynamic Screen Contrast | 100000000 : 1 | 20000000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° | 170 ° |
| Screen Vertical Viewing Angle | 160 ° | 160 ° |
| Display Minimum Response Time | 5 ms | 5 ms |
| Display Coating | Anti-glare/Matte (3H) | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 1.9 in 4.8 cm 48.3 mm 0.16 ft |
|
| Case Width with Stand | 18.29 in 46.5 cm 464.5 mm 1.52 ft |
|
| Case Height with Stand | 13.63 in 34.6 cm 346.3 mm 1.14 ft |
|
| Case Depth with Stand | 6.93 in 17.6 cm 176 mm 0.58 ft |
|
| Case Weight with Stand | 2.27 kg 5 lbs |
|
| Case Color | Black | Black |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x HDMI 1.4 1 x D-sub |
1 x D-sub |
| Audio | ||
| Features | ||
| Cool Features | Flicker-free technology Adaptive Contrast Management (ACM) BluelightShield |
|
| Extra Features | Anti-theft stand lock slot - Kensington | |
| Ergonomics | ||
| Case Width | 18.29 in 46.5 cm 464.5 mm 1.52 ft |
|
| Case Height | 11.03 in 28 cm 280.2 mm 0.92 ft |
|
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 75 x 75 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | No |
| Landscape or Portrait Pivot Support | No | No |
| Left or Right Swivel Support | No | No |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 4 ° | 3 ° |
| Backward Tilt | 14 ° | 10 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 50 Hz - 76 Hz | |
| Horizontal Digital Frequency | 30 kHz - 83 kHz | |
| Screen Interpolation Measurement Unit | NULL | |
| Accessories | ||
| Extras | D-sub cable | |
| Certificates and Standards | ||
| Licenses | CE EAC ENERGY STAR 6.0 Epeat Silver FCC Class B RoHS TCO Certified Displays TÜV/GS |
|
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
|
| Safe Operating Humidity Level | 20 % - 80 % | |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| AOpen 20CH1Q | AOC E2070SWN |
