| General Info | ||
|---|---|---|
| Model Number | EIZO EV2336W | EIZO FlexScan S1934 |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2012 | 2016 |
| Brand | EIZO | EIZO |
| Model Series | FlexScan | |
| Model Number | EV2336W | FlexScan S1934 |
| Display | ||
| Screen Size Class | 23" (inches) | 19" (inches) |
| Diagonal Size | 23 in 58.4 cm 584.2 mm 1.92 ft |
18.9 in 48 cm 480 mm 1.57 ft |
| Screen Width | 20.07 in 51 cm 509.76 mm 1.67 ft |
14.76 in 37.5 cm 374.78 mm 1.23 ft |
| Screen Height | 11.29 in 28.7 cm 286.74 mm 0.94 ft |
11.8 in 30 cm 299.83 mm 0.98 ft |
| Display Manufacturer | Samsung | |
| Display Type | PLS | IPS |
| Display Bit Depth | 8 bits | 8 bits |
| Frame Rate Control | No | |
| Max Number of Colors | 16777216 | 16777216 |
| Bits | 24 | 24 |
| Screen Aspect Ratio | 16:9 | 5:4 |
| Screen Resolution | 1920 x 1080 | 1280 x 1024 |
| Screen Pixel Pitch | 0.266 mm | 0.293 mm |
| Screen Pixel Density | 95 ppi | 86 ppi |
| Screen-to-Body Ratio | 85.25 % | 83.07 % |
| Backlight Source | W-LED | W-LED |
| Screen Brightness | 300 cd/m² | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 | 1000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° | 178 ° |
| Screen Vertical Viewing Angle | 160 ° | 178 ° |
| Screen Input Lag | 1 ms | |
| Display Minimum Response Time | 6 ms | |
| Display Average Response Time | 13 ms | 14 ms |
| Display Maximum Response Time | 16 ms | |
| Display Coating | Anti-glare/Matte (3H) | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 2.2 in 5.6 cm 56 mm 0.18 ft |
2.42 in 6.2 cm 61.5 mm 0.2 ft |
| Case Weight | 3.7 kg 8 lbs |
3.8 kg 8 lbs |
| Case Width with Stand | 21.26 in 54 cm 540 mm 1.77 ft |
15.94 in 40.5 cm 405 mm 1.33 ft |
| Case Height with Stand | 14.49 in 36.8 cm 368 mm 1.21 ft |
16.3 in 41.4 cm 414 mm 1.36 ft |
| Case Depth with Stand | 9.17 in 23.3 cm 233 mm 0.76 ft |
8.07 in 20.5 cm 205 mm 0.67 ft |
| Case Weight with Stand | 6.1 kg 13 lbs |
5.6 kg 12 lbs |
| Case Color | Black, Gray | White, Gray |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x DisplayPort 1 x DVI-D Dual Link 1 x D-sub 2 x USB 2.0 (downstream) 1 x USB 2.0 (upstream) |
1 x D-sub 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x DisplayPort 1.2 1 x DVI-D Dual Link |
| Audio | ||
| Audio Speakers | 2 x 1W | 2 x 0.5W |
| Features | ||
| Cool Features | Light sensor Paper mode Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
HDCP (High-bandwidth Digital Content Protection) Light sensor Low Blue Light EcoView Flicker-free technology |
| Ergonomics | ||
| Case Width | 21.26 in 54 cm 540 mm 1.77 ft |
15.94 in 40.5 cm 405 mm 1.33 ft |
| Case Height | 12.5 in 31.8 cm 317.5 mm 1.04 ft |
13.15 in 33.4 cm 334 mm 1.1 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | Yes | Yes |
| Height Adjustment Range | 140 mm 14 cm 5.5118 in 0.4593 ft |
100 mm 10 cm 3.937 in 0.3281 ft |
| Landscape or Portrait Pivot Support | Yes | Yes |
| Left Pivot | 0 ° | 0 ° |
| Right Pivot | 90 ° | 90 ° |
| Left or Right Swivel Support | Yes | Yes |
| Left Swivel | 172 ° | 35 ° |
| Right Swivel | 172 ° | 35 ° |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 5 ° | 5 ° |
| Backward Tilt | 35 ° | 30 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 59 Hz - 61 Hz | 59 Hz - 61 Hz |
| Horizontal Digital Frequency | 31 kHz - 68 kHz | 31 kHz - 64 kHz |
| Accessories | ||
| Extras | DisplayPort cable DVI-D cable |
Audio cable D-sub cable DVI-D cable |
| Certificates and Standards | ||
| Licenses | CB CCC CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Certified Displays 6.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
CB CCC CE cTÜVus EAC ENERGY STAR 6.0 Epeat Gold FCC Class B ICES-003-B RCM RoHS TÜV/Ergonomics TÜV/GS TÜV/S VCCI-B WEEE |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
|
| Internal Storage Humidity | 10 % - 90 % |
| EIZO EV2336W | EIZO FlexScan S1934 |
