| General Info | ||
|---|---|---|
| Model Number | MSI Optix MAG301CR2 | AOC 24G2 |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2020 | 2020 |
| Brand | MSI | AOC |
| Model Series | MAG | |
| Model Number | Optix MAG301CR2 | 24G2 |
| Alias | 3CB4 | 24G2/BK |
| Display | ||
| Screen Size Class | 30" (inches) | 24" (inches) |
| Diagonal Size | 29.5 in 74.9 cm 749.358 mm 2.46 ft |
23.81 in 60.5 cm 604.7 mm 1.98 ft |
| Screen Width | 27.18 in 69 cm 690.432 mm 2.27 ft |
20.75 in 52.7 cm 527.04 mm 1.73 ft |
| Screen Height | 11.47 in 29.1 cm 291.276 mm 0.96 ft |
11.67 in 29.6 cm 296.46 mm 0.97 ft |
| Display Curvature | 1500 | |
| Display Manufacturer | Panda | |
| Display Type | VA | IPS |
| Display Bit Depth | 10 bits (8 bits + FRC) | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 1073741824 | 16777216 |
| Bits | 30 | 24 |
| Screen Aspect Ratio | 21:9 | 16:9 |
| Screen Resolution | 2560 x 1080 | 1920 x 1080 |
| Screen Pixel Pitch | 0.27 mm | 0.275 mm |
| Screen Pixel Density | 94 ppi | 92 ppi |
| Backlight Source | W-LED | W-LED |
| DCI P3 | 98.29% | |
| sRGB | 127.39 % | 126 % |
| Adobe RGB 1998 | 94 % | |
| Screen Brightness | 300 cd/m² | 250 cd/m² |
| Static Screen Contrast | 3000 : 1 | 1000 : 1 |
| Dynamic Screen Contrast | 20000000 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Display Minimum Response Time | 1 ms | 1 ms |
| Display Average Response Time | 5 ms | |
| Display Coating | Anti-glare/Matte | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Weight | 2.95 kg 6 lbs |
|
| Case Width with Stand | 27.67 in 70.3 cm 702.9 mm 2.31 ft |
21.22 in 53.9 cm 539.05 mm 1.77 ft |
| Case Height with Stand | 16.22 in 41.2 cm 412 mm 1.35 ft |
14.75 in 37.5 cm 374.61 mm 1.23 ft |
| Case Depth with Stand | 11.3 in 28.7 cm 286.9 mm 0.94 ft |
8.95 in 22.7 cm 227.36 mm 0.75 ft |
| Case Weight with Stand | 5.8 kg 13 lbs |
4.25 kg 9 lbs |
| Case Color | Black | Black |
| Hardware | ||
| Built-in Camera | No | |
| Connectivity | 1 x USB 3.2 (Type-C; Gen 1; 15W; DP Alt Mode) 2 x HDMI 2.0 (b) 1 x 3.5 mm Audio Out 1 x DisplayPort 1.2 (a) 2 x USB 3.2 (Type-A; Gen 1; downstream) 1 x USB 3.2 (Type-B; Gen 1; upstream) |
1 x D-sub 1 x 3.5 mm Microphone In 1 x 3.5 mm Audio Out 2 x HDMI 1.4 1 x DisplayPort 1.2 |
| Audio | ||
| Audio Speakers | 2 x 2W | |
| Features | ||
| Cool Features | Frameless Design Gaming OSD App Wide Color Gamut Low Blue Light MSI Mystic Light Wide Viewing Angle MSI Macro Key HDR Ready AMD FreeSync Premium Navi Key Flicker-free technology Night Vision |
Low Blue Light AMD FreeSync technology Flicker-free technology |
| Extra Features | Anti-theft stand lock slot - Kensington | |
| Ergonomics | ||
| Case Width | 27.67 in 70.3 cm 702.9 mm 2.31 ft |
|
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 75 x 75 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | Yes | Yes |
| Height Adjustment Range | 110 mm 11 cm 4.3307 in 0.3609 ft |
130 mm 13 cm 5.1181 in 0.4265 ft |
| Landscape or Portrait Pivot Support | Yes | Yes |
| Left Pivot | 90 ° | 0 ° |
| Right Pivot | 90 ° | 90 ° |
| Left or Right Swivel Support | Yes | Yes |
| Left Swivel | 30 ° | |
| Right Swivel | 30 ° | 30 ° |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 5 ° | 4 ° |
| Backward Tilt | 20 ° | 21.5 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 48 Hz - 200 Hz | 48 Hz - 146 Hz |
| Horizontal Digital Frequency | 66 kHz - 250.7 kHz | 30 kHz - 160 kHz |
| Screen Interpolation Measurement Unit | NULL | |
| Accessories | ||
| Extras | DisplayPort cable (optional) HDMI cable (optional) USB upstream cable (optional) |
DisplayPort cable HDMI cable |
| Certificates and Standards | ||
| Licenses | CE FCC-B RoHS WEEE |
|
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 10 °C - 40 °C 50 °F - 104 °F |
|
| Safe Operating Humidity Level | 20 % - 90 % | |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
|
| Internal Storage Humidity | 10 % - 90 % | |
| Max Operating Altitude | 2000 |
| MSI Optix MAG301CR2 | AOC 24G2 |
