| General Info | ||
|---|---|---|
| Model Number | TCL 55S403 | TCL 55S535 |
|
|
|
| Price | ||
| Type | TV | TV |
| Year | 2017 | 2020 |
| Brand | TCL | TCL |
| Model Series | S403 | S535 |
| Model Number | 55S403 | 55S535 |
| Display | ||
| Screen Size Class | 55" (inches) | 55" (inches) |
| Diagonal Size | 54.65 in 138.8 cm 1388 mm 4.55 ft |
54.65 in 138.8 cm 1388 mm 4.55 ft |
| Screen Width | 47.62 in 121 cm 1209.6 mm 3.97 ft |
47.62 in 121 cm 1209.6 mm 3.97 ft |
| Screen Height | 26.79 in 68 cm 680.4 mm 2.23 ft |
26.79 in 68 cm 680.4 mm 2.23 ft |
| Display Manufacturer | CSOT | |
| Display Type | VA | VA |
| Display Bit Depth | 10 bits (8 bits + FRC) | 10 bits |
| Frame Rate Control | Yes | |
| Max Number of Colors | 1073741824 | 1073741824 |
| Bits | 30 | 30 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 3840 x 2160 | 3840 x 2160 |
| Screen Pixel Pitch | 0.315 mm | 0.315 mm |
| Screen Pixel Density | 80 ppi | 80 ppi |
| Screen-to-Body Ratio | 91.16 % | 93.8 % |
| Backlight Source | Direct LED | Direct LED (Full-Array Local Dimming) |
| DCI P3 | 94% | |
| Screen Brightness | 300 cd/m² | |
| Static Screen Contrast | 7200 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Screen Input Lag | 11 ms | |
| Display Minimum Response Time | 5 ms | |
| Display Maximum Response Time | 12 ms | |
| Display Coating | Glossy | |
| HDR | HDR10 | HDR10 HLG (Hybrid Log Gamma) Dolby Vision |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 3 in 7.6 cm 76.2 mm 0.25 ft |
3 in 7.6 cm 76.2 mm 0.25 ft |
| Case Weight | 13.4 kg 29 lbs |
14.8 kg 33 lbs |
| Case Width with Stand | 49.1 in 124.7 cm 1247.14 mm 4.09 ft |
48.4 in 122.9 cm 1229.36 mm 4.03 ft |
| Case Height with Stand | 30.8 in 78.2 cm 782.32 mm 2.57 ft |
30.1 in 76.5 cm 764.54 mm 2.51 ft |
| Case Depth with Stand | 8.7 in 22.1 cm 221 mm 0.73 ft |
11.6 in 29.5 cm 294.64 mm 0.97 ft |
| Case Weight with Stand | 13.6 kg 30 lbs |
15.1 kg 33 lbs |
| Case Color | Black | Black |
| Hardware | ||
| CPU Cores | 2 | 2 |
| GPU Cores | 2 | 2 |
| TV Tuner | Analog (NTSC/PAL/SECAM) Clear QAM ATSC |
Analog (NTSC/PAL/SECAM) ATSC Clear QAM |
| Built-in Camera | No | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) |
LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi Direct |
| Connectivity | 3 x HDMI 2.0 (ARC; CEC) 1 x Satellite In (Main; F-type female) 1 x S/PDIF 1 x 3.5 mm Audio Out 1 x AV Composite In (Video + L/R) 1 x USB 2.0 (max 0.5 A) 1 x Ethernet RJ45 |
4 x HDMI 2.0 1 x Satellite In (F-type female) 1 x S/PDIF 1 x 3.5 mm Audio Out 1 x AV Composite In 3.5 mm jack 1 x USB 2.0 1 x Ethernet RJ45 |
| Audio | ||
| Audio Speakers | 2 x 8W | 2 x 8W |
| Features | ||
| OS | Roku TV | Roku TV |
| Cool Features | HDCP (High-bandwidth Digital Content Protection) 2.2 | Auto Game Mode Contrast Control Zone technology with 80 zones Smart HDR FullView edge-to-edge glass design Quantum Dot Color V-Chip Google Assistant Easy Voice Control AiPQ Engine Smart 4K Upscaling Alexa Smart Contrast |
| Ergonomics | ||
| Case Width | 49.1 in 124.7 cm 1247.14 mm 4.09 ft |
48.4 in 122.9 cm 1229.36 mm 4.03 ft |
| Case Height | 28.5 in 72.4 cm 723.9 mm 2.38 ft |
28.1 in 71.4 cm 713.74 mm 2.34 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 200 x 200 | 300 x 200 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | No |
| Landscape or Portrait Pivot Support | No | No |
| Left or Right Swivel Support | No | No |
| Forward and Backward Tilt Support | No | No |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 60 Hz | 50 Hz / 60 Hz |
| Screen Interpolation Technology | Clear Motion Index | Natural Motion |
| Screen Interpolation Value | 120 | 240 |
| Screen Interpolation Measurement Unit | CMI | NM |
| Accessories | ||
| Extras | Remote control - RC282 | Remote control - RC280 |
| Certificates and Standards | ||
| Licenses | RoHS | |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
-15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % | 10 % - 90 % |
| TCL 55S403 | TCL 55S535 |
