| General Info | ||
|---|---|---|
| Model Number | TCL Xess X2 U65X9006 | TCL 65DC760 |
|
|
|
| Price | ||
| Type | TV | TV |
| Year | 2017 | 2018 |
| Brand | TCL | TCL |
| Model Series | X2 | C76 |
| Model Number | Xess X2 U65X9006 | 65DC760 |
| Alias | U65X9006 | |
| Display | ||
| Screen Size Class | 65" (inches) | 65" (inches) |
| Diagonal Size | 64.53 in 163.9 cm 1639 mm 5.38 ft |
64.53 in 163.9 cm 1639 mm 5.38 ft |
| Screen Width | 56.24 in 142.8 cm 1428.48 mm 4.69 ft |
56.24 in 142.8 cm 1428.48 mm 4.69 ft |
| Screen Height | 31.63 in 80.4 cm 803.52 mm 2.64 ft |
31.63 in 80.4 cm 803.52 mm 2.64 ft |
| Display Type | VA | VA |
| Display Bit Depth | 10 bits | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes | |
| Max Number of Colors | 1073741824 | 1073741824 |
| Bits | 30 | 30 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 3840 x 2160 | 3840 x 2160 |
| Screen Pixel Pitch | 0.372 mm | 0.372 mm |
| Screen Pixel Density | 68 ppi | 68 ppi |
| Screen-to-Body Ratio | 93.24 % | 92.07 % |
| Backlight Source | Edge LED | Edge LED |
| DCI P3 | 100% | 95% |
| Rec.2020 | 75 | 72 |
| Screen Brightness | 350 cd/m² | 400 cd/m² |
| Max Screen Brightness | 600 cd/m² | |
| Static Screen Contrast | 3000 : 1 | 4000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Screen Input Lag | 30 ms | 25 ms |
| HDR | HDR Pro HDR10 HLG (Hybrid Log Gamma) |
HDR10 HLG (Hybrid Log Gamma) |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 2.28 in 5.8 cm 58 mm 0.19 ft |
2.87 in 7.3 cm 73 mm 0.24 ft |
| Case Weight | 22.6 kg 50 lbs |
25 kg 55 lbs |
| Case Width with Stand | 57.56 in 146.2 cm 1462 mm 4.8 ft |
57.01 in 144.8 cm 1448 mm 4.75 ft |
| Case Height with Stand | 34.65 in 88 cm 880 mm 2.89 ft |
36.65 in 93.1 cm 931 mm 3.05 ft |
| Case Depth with Stand | 12.2 in 31 cm 310 mm 1.02 ft |
12.91 in 32.8 cm 328 mm 1.08 ft |
| Case Weight with Stand | 23 kg 51 lbs |
29 kg 64 lbs |
| Case Color | Gray | Black |
| Hardware | ||
| System on Chip or SoC | Mediatek MT5891 | MediaTek MT5891 |
| CPU | ARM Cortex-A53 | ARM Cortex-A53 |
| CPU Cores | 4 | 4 |
| CPU Frequency | 1100 | 1100 |
| GPU | ARM Mali-T860 MP2 | ARM Mali-T860 MP2 |
| GPU Cores | 2 | 2 |
| GPU Frequency | 700 | 700 |
| RAM Memory Size | 2 | 2 |
| Internal Storage | 16 | 16 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T DVB-T2 DVB-C DVB-S DVB-S2 |
Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
| Built-in Camera | No | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Bluetooth Wi-Fi Direct DLNA |
LAN Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 1 x Ethernet RJ45 3 x HDMI 2.0 (ARC; CEC; MHL) 1 x AV Composite In 3.5 mm jack 1 x 3.5 mm Audio Out 1 x Optical Audio Out 1 x Satellite In (Main; F-type female) 1 x USB 2.0 1 x Antenna (RF) (female) 1 x USB 3.0 1 x CI+ 1.3 |
1 x Ethernet RJ45 3 x HDMI 2.0 (ARC; CEC; MHL) 1 x Video Component In 3.5 mm jack 1 x 3.5 mm Audio Out 1 x S/PDIF 1 x Satellite In (Main; F-type female) 1 x USB 2.0 1 x Antenna (RF) (female) 1 x USB 3.0 1 x CI+ |
| Audio | ||
| Audio Speakers | 2 x 20W | 2 x 15W |
| Features | ||
| OS | Android 6.0.1 Marshmallow Android 7.0 Nougat |
Android 7.0 Nougat Android 8.0 Oreo |
| Cool Features | Micro Dimming Picture Noise Reduction UHD Premium Color Enhancer Wide Color Gamut UHD Upscaling Quantum Dot Display HDCP (High-bandwidth Digital Content Protection) 2.2 Mega Dynamic Contrast |
Micro Dimming Picture Noise Reduction Smart HDR UHD Upscaling UHD Color Extender Pure Image Ultra HD HDCP (High-bandwidth Digital Content Protection) 2.2 Voice command Mega Dynamic Contrast Wide Color Gamut |
| Ergonomics | ||
| Case Width | 57.56 in 146.2 cm 1462 mm 4.8 ft |
57.01 in 144.8 cm 1448 mm 4.75 ft |
| Case Height | 33.15 in 84.2 cm 842 mm 2.76 ft |
33.9 in 86.1 cm 861 mm 2.82 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 600 x 200 | 400 x 200 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | No |
| Landscape or Portrait Pivot Support | No | No |
| Left or Right Swivel Support | No | No |
| Forward and Backward Tilt Support | No | No |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 60 Hz | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index | Picture Performance Index |
| Screen Interpolation Value | 2100 | 1700 |
| Screen Interpolation Measurement Unit | PPI | PPI |
| Accessories | ||
| Extras | Remote control - RC64 | Remote control - RC802N1 Smart remote control - RC602S1 |
| Certificates and Standards | ||
| Licenses | ENERGY STAR RoHS UL/cUL |
RoHS |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
-15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % | 10 % - 90 % |
| TCL Xess X2 U65X9006 | TCL 65DC760 |
