| Brand | Acer |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | TN |
| Refresh Rate | 75 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1680 x 1050 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2013 |
| Brand | Acer |
| Model Number | B226WL ymdpr |
| Size | 22" (inches) |
| Panel | TN |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 22 in 55.9 cm 558.8 mm 1.83 ft |
| Screen Width | 18.65 in 47.4 cm 473.76 mm 1.55 ft |
| Screen Height | 11.66 in 29.6 cm 296.1 mm 0.97 ft |
| Display Type | TN |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1680 x 1050 |
| Screen Pixel Pitch | 0.282 mm |
| Screen Pixel Density | 90 ppi |
| Screen-to-Body Ratio | 83.29 % |
| Backlight Source | W-LED |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Dynamic Screen Contrast | 100000000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° |
| Screen Vertical Viewing Angle | 160 ° |
| Display Minimum Response Time | 5 ms |
| Display Coating | Anti-glare/Matte |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.05 in 5.2 cm 52 mm 0.17 ft |
| Case Weight | 3.1 kg 7 lbs |
| Case Width with Stand | 19.91 in 50.6 cm 505.8 mm 1.66 ft |
| Case Height with Stand | 15.12 in 38.4 cm 384.1 mm 1.26 ft |
| Case Depth with Stand | 8.71 in 22.1 cm 221.2 mm 0.73 ft |
| Case Weight with Stand | 5.8 kg 13 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x D-sub 1 x 3.5 mm Audio Out 1 x DisplayPort 1 x DVI-D Dual Link |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Anti-theft stand lock slot - Kensington |
| Ergonomics | |
| Case Width | 19.91 in 50.6 cm 505.8 mm 1.66 ft |
| Case Height | 13.11 in 33.3 cm 333 mm 1.09 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 60 ° |
| Right Swivel | 60 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 55 Hz - 75 Hz |
| Horizontal Digital Frequency | 30 kHz - 80 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.35 W |
| Power Consumption in Sleep Mode | 0.45 W |
| Average Power Consumption | 17.2 W |
| Maximum Power Consumption | 24.2 W |
| Accessories | |
| Extras | D-sub cable DVI-D cable |
| Certificates and Standards | |
| Licenses | CE ENERGY STAR TCO Certified Displays |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 65 °C -4 °F - 149 °F |
| Internal Storage Humidity | 10 % - 90 % |
