| Brand | AOC |
| Type | Monitor |
| Size | 20" (inches) |
| Panel | TN |
| Refresh Rate | 76 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1600 x 900 |
| General Info | Type | Monitor |
|---|---|---|
| Year | 2013 | |
| Brand | AOC | |
| Model Number | E2060PWDA | |
| Size | 20" (inches) | |
| Panel | TN | |
| Display | Screen Size Class | 20" (inches) |
| Diagonal Size | 19.45 in 49.4 cm 494 mm 1.62 ft |
|
| Screen Width | 17.01 in 43.2 cm 432 mm 1.42 ft |
|
| Screen Height | 9.44 in 24 cm 239.76 mm 0.79 ft |
|
| Display Manufacturer | Innolux | |
| Display Type | TN | |
| Display Bit Depth | 8 bits (6 bits + FRC) | |
| Frame Rate Control | Yes | |
| Max Number of Colors | 16777216 | |
| Bits | 24 | |
| Screen Aspect Ratio | 16:9 | |
| Screen Resolution | 1600 x 900 | |
| Screen Pixel Pitch | 0.27 mm | |
| Screen Pixel Density | 94 ppi | |
| Backlight Source | W-LED | |
| NTSC 1953 | 72 % | |
| Screen Brightness | 250 cd/m² | |
| Static Screen Contrast | 1000 : 1 | |
| Dynamic Screen Contrast | 20000000 : 1 | |
| Screen Horizontal Viewing Angle | 170 ° | |
| Screen Vertical Viewing Angle | 160 ° | |
| Display Minimum Response Time | 5 ms | |
| Display Coating | Anti-glare/Matte (3H) | |
| 3D | No | |
| Size, weight, color | Case Width with Stand | 18.8 in 47.8 cm 477.6 mm 1.57 ft |
| Case Height with Stand | 14.88 in 37.8 cm 377.9 mm 1.24 ft |
|
| Case Depth with Stand | 9.63 in 24.5 cm 244.5 mm 0.8 ft |
|
| Case Weight with Stand | 4.7 kg 10 lbs |
|
| Case Color | Black | |
| Hardware | Built-in Camera | No |
| Connectivity | 1 x 3.5 mm Audio Out 1 x DVI-D 1 x D-sub |
|
| Audio | Audio Speakers | 2 x 2W |
| Features | Cool Features | HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Anti-theft stand lock slot - Kensington | |
| Ergonomics | Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 | |
| Removable VESA Stand | Yes | |
| Height Adjustment | Yes | |
| Height Adjustment Range | 130 mm 13 cm 5.1181 in 0.4265 ft |
|
| Landscape or Portrait Pivot Support | Yes | |
| Left Pivot | 0 ° | |
| Right Pivot | 90 ° | |
| Left or Right Swivel Support | Yes | |
| Left Swivel | 60 ° | |
| Right Swivel | 60 ° | |
| Forward and Backward Tilt Support | Yes | |
| Forward Tilt | 5 ° | |
| Backward Tilt | 15 ° | |
| Frequency and Interpolation | Vertical Digital Frequency | 50 Hz - 76 Hz |
| Horizontal Digital Frequency | 30 kHz - 83 kHz | |
| Power | 110V | 100 V - 120 V |
| 220V | 220 V - 240 V | |
| AC Frequency | 50 Hz - 60 Hz | |
| Power Consumption When Device is Off | 0.5 W | |
| Power Consumption in Sleep Mode | 0.5 W | |
| Average Power Consumption | 23 W | |
| Accessories | Extras | Audio cable D-sub cable |
| Certificates and Standards | Licenses | CE EAC ENERGY STAR Epeat Gold FCC Class B RoHS TCO Certified Displays TÜV/GS |
