| Brand | NEC |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | IPS |
| Refresh Rate | 75 Hz |
| Min Response Time | 6 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2017 |
| Brand | NEC |
| Model Number | AccuSync AS224WMi |
| Alias | AS224WMI-BK |
| Size | 22" (inches) |
| Panel | IPS |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 21.5 in 54.6 cm 546.1 mm 1.79 ft |
| Screen Width | 18.75 in 47.6 cm 476.16 mm 1.56 ft |
| Screen Height | 10.54 in 26.8 cm 267.84 mm 0.88 ft |
| Display Type | IPS |
| Display Bit Depth | 8 bits |
| Frame Rate Control | No |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.248 mm |
| Screen Pixel Density | 102 ppi |
| Screen-to-Body Ratio | 83.48 % |
| Backlight Source | W-LED |
| NTSC 1953 | 72 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 6 ms |
| Display Coating | Anti-glare/Matte |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.3 in 5.9 cm 58.5 mm 0.19 ft |
| Case Weight | 3.7 kg 8 lbs |
| Case Width with Stand | 19.98 in 50.7 cm 507.4 mm 1.66 ft |
| Case Height with Stand | 14.36 in 36.5 cm 364.7 mm 1.2 ft |
| Case Depth with Stand | 8.07 in 20.5 cm 205.1 mm 0.67 ft |
| Case Weight with Stand | 4.1 kg 9 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x D-sub 1 x 3.5 mm Audio Out 1 x DisplayPort 1.2 1 x DVI-D Dual Link |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | XtraView EcoModes HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Case Width | 19.98 in 50.7 cm 507.4 mm 1.66 ft |
| Case Height | 11.85 in 30.1 cm 301.1 mm 0.99 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 20 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 56 Hz - 75 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 81.1 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.35 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 18 W |
| Accessories | |
| Extras | D-sub cable |
| Certificates and Standards | |
| Licenses | CCC CE EAC ENERGY STAR 6.0 ErP FCC Class B ISO 9241-307 MPR II / MPR III PSB RoHS TCO 7.0 TÜV/Ergonomics TÜV/GS UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -10 °C - 60 °C 14 °F - 140 °F |
| Internal Storage Humidity | 10 % - 85 % |
| Max Operating Altitude | 2000 |
| Max Storage Altitude | 12192 |
