| Brand | NEC |
| Type | Monitor |
| Size | 30" (inches) |
| Panel | AH-IPS |
| Refresh Rate | 85 Hz |
| Min Response Time | 7 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 2560 x 1600 |
| Price | 1999.99 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2013 |
| Brand | NEC |
| Model Number | MultiSync PA302W-BK-SV |
| Size | 30" (inches) |
| Panel | AH-IPS |
| Display | |
| Screen Size Class | 30" (inches) |
| Diagonal Size | 29.77 in 75.6 cm 756.2 mm 2.48 ft |
| Screen Width | 25.25 in 64.1 cm 641.28 mm 2.1 ft |
| Screen Height | 15.78 in 40.1 cm 400.8 mm 1.31 ft |
| Display Manufacturer | LG Display |
| Display Type | AH-IPS |
| Display Bit Depth | 10 bits |
| Lut | 3D LUT 14 bits |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 2560 x 1600 |
| Screen Pixel Pitch | 0.251 mm |
| Screen Pixel Density | 101 ppi |
| Screen-to-Body Ratio | 83.61 % |
| Backlight Source | GB-r LED |
| sRGB | 146.4 % |
| Adobe RGB 1998 | 99.3 % |
| NTSC 1953 | 94.8 % |
| Screen Brightness | 340 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Screen Input Lag | 34 ms |
| Display Minimum Response Time | 7 ms |
| Display Average Response Time | 15 ms |
| Display Maximum Response Time | 18 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 3.23 in 8.2 cm 82 mm 0.27 ft |
| Case Weight | 10.7 kg 24 lbs |
| Case Width with Stand | 27.1 in 68.8 cm 688.3 mm 2.26 ft |
| Case Height with Stand | 18.36 in 46.6 cm 466.4 mm 1.53 ft |
| Case Depth with Stand | 11.87 in 30.2 cm 301.6 mm 0.99 ft |
| Case Weight with Stand | 17 kg 37 lbs |
| Case Color | Black, White |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x HDMI 1.4 1 x DisplayPort 1.2 1 x DVI-D Dual Link 1 x DisplayPort 1.2 (mini) 3 x USB 2.0 (downstream) 2 x USB 2.0 (upstream) |
| Audio | |
| Features | |
| Cool Features | Carbon Footprint Meter XtraView+ Digital Uniformity Correction SpectraView II HDCP (High-bandwidth Digital Content Protection) Picture-by-Picture TileMatrix Standalone hardware calibration Light sensor DisplaySync Pro Black Level Adjusment TileComp Picture-in-Picture CableComp Self Diagnostics |
| Ergonomics | |
| Case Width | 27.09 in 68.8 cm 688 mm 2.26 ft |
| Case Height | 17.59 in 44.7 cm 446.8 mm 1.47 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 45 ° |
| Right Swivel | 45 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 30 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 50 Hz - 85 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 98.7 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Electric Power in Amperes | 1.1 A |
| Power Consumption When Device is Off | 0.2 W |
| Power Consumption in Sleep Mode | 1.4 W |
| Average Power Consumption | 52 W |
| Power Consumption in Eco Mode | 32 W |
| Maximum Power Consumption | 96 W |
| Accessories | |
| Extras | Color calibration sensor (MDSVSENSOR3) DVI cable DisplayPort cable DisplayPort cable - mini-DP to DP USB cable |
| Certificates and Standards | |
| Licenses | C-Tick CCC CE ErP FCC Class B ISO 9241-307 MPR II / MPR III PCBC/B-mark PCT/Gost PSB RoHS TÜV/Ergonomics TÜV/GS UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 10 % - 85 % |
| Max Operating Altitude | 5000 |
| Max Storage Altitude | 12192 |
