| Brand | ViewSonic |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | TN |
| Refresh Rate | 75 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2013 |
| Brand | ViewSonic |
| Model Number | VA2246m-LED |
| Size | 22" (inches) |
| Panel | TN |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 21.5 in 54.6 cm 546.1 mm 1.79 ft |
| Screen Width | 18.77 in 47.7 cm 476.64 mm 1.56 ft |
| Screen Height | 10.56 in 26.8 cm 268.11 mm 0.88 ft |
| Display Manufacturer | Innolux |
| Display Type | TN |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.248 mm |
| Screen Pixel Density | 102 ppi |
| Screen-to-Body Ratio | 79.21 % |
| Backlight Source | W-LED |
| NTSC 1953 | 72 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Dynamic Screen Contrast | 50000000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° |
| Screen Vertical Viewing Angle | 160 ° |
| Display Minimum Response Time | 5 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 1.9 in 4.8 cm 48.3 mm 0.16 ft |
| Case Weight | 3.13 kg 7 lbs |
| Case Width with Stand | 20.06 in 51 cm 509.6 mm 1.67 ft |
| Case Height with Stand | 14.41 in 36.6 cm 366.1 mm 1.2 ft |
| Case Depth with Stand | 7.78 in 19.8 cm 197.6 mm 0.65 ft |
| Case Weight with Stand | 3.48 kg 8 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x 3.5 mm Audio In 1 x DVI-D Dual Link 1 x D-sub |
| Audio | |
| Audio Speakers | 2 x 2W |
| Features | |
| Extra Features | Anti-theft stand lock slot - Kensington |
| Ergonomics | |
| Case Width | 20.06 in 51 cm 509.6 mm 1.67 ft |
| Case Height | 12.46 in 31.7 cm 316.6 mm 1.04 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 18 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 50 Hz - 75 Hz |
| Horizontal Digital Frequency | 24 kHz - 82 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 16 W |
| Power Consumption in Eco Mode | 12 W |
| Maximum Power Consumption | 22 W |
| Accessories | |
| Extras | Audio cable D-sub cable |
| Certificates and Standards | |
| Licenses | CB CCC CE CEL Level 1 CU ENERGY STAR ErP eStandby FCC Class B REACH SVHC List & DoC RoHS VCCI WEEE |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 20 % - 90 % |
| Internal Storage Temperature | -25 °C - 60 °C -13 °F - 140 °F |
| Internal Storage Humidity | 5 % - 90 % |
| Max Operating Altitude | 5000 |
| Max Storage Altitude | 12192 |
