| Brand | LG |
| Type | TV |
| Size | 77" (inches) |
| Panel | OLED |
| Refresh Rate | 120 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2014 |
| Brand | LG |
| Model Series | EC980 |
| Model Number | 77EC980V |
| Size | 77" (inches) |
| Panel | OLED |
| Operating System | webOS |
| Display | |
| Screen Size Class | 77" (inches) |
| Diagonal Size | 76.77 in 195 cm 1950 mm 6.4 ft |
| Screen Width | 66.91 in 170 cm 1699.57 mm 5.58 ft |
| Screen Height | 37.64 in 95.6 cm 956.009 mm 3.14 ft |
| Display Curvature | 5000 |
| Display Manufacturer | LG Display |
| Display Type | OLED |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.443 mm |
| Screen Pixel Density | 57 ppi |
| Screen-to-Body Ratio | 88.89 % |
| Backlight Source | Direct LED |
| Screen Brightness | 400 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| 3D | Yes |
| Size, weight, color | |
| Case Depth | 1.33 in 3.4 cm 33.7 mm 0.11 ft |
| Case Weight | 39.9 kg 88 lbs |
| Case Width with Stand | 67.64 in 171.8 cm 1718 mm 5.64 ft |
| Case Height with Stand | 43.7 in 111 cm 1110 mm 3.64 ft |
| Case Depth with Stand | 12.68 in 32.2 cm 322 mm 1.06 ft |
| Case Weight with Stand | 43.3 kg 95 lbs |
| Case Color | Black |
| Hardware | |
| CPU Cores | 2 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T DVB-T2 DVB-S2 DVB-S DVB-C |
| Built-in Camera | Yes |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 1 x Ethernet RJ45 4 x HDMI 2.0 (ARC; CEC; MHL) 1 x RS232 (C) 1 x SCART 1 x Video Component In 3.5 mm jack 1 x Antenna (RF) (female) 1 x AV Composite In 3.5 mm jack 1 x Satellite In (Main; F-type female) 2 x USB 2.0 1 x CI+ 1.3 1 x Optical Audio Out 1 x USB 3.0 1 x 3.5 mm Audio Out |
| Audio | |
| Audio Speakers | 4 x 17.5W |
| Features | |
| OS | webOS |
| Cool Features | Clear Voice II Voice command Dynamic Clear White Tru-Black Control HDCP (High-bandwidth Digital Content Protection) 2.2 Picture Wizard III ULTRA Surround Tru Color Generator Pixel Dimming Dynamic Color Enhancer 4K Upscaler ULTRA HD Engine Pro SIMPLINK (HDMI CEC) Active Noise Reduction Triple XD Engine |
| Ergonomics | |
| Case Width | 67.64 in 171.8 cm 1718 mm 5.64 ft |
| Case Height | 41.89 in 106.4 cm 1064 mm 3.49 ft |
| Vesa Mount Support | No |
| VESA Interface Standard Size | 400 x 400 |
| Removable VESA Stand | No |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 120 Hz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 296 W |
| Energy Class | B |
| Accessories | |
| Extras | 2 x 3D passive glasses - AG-F315 3.5 mm component adapter 3.5 mm composite adapter Magic remote control - AN-MR500 Remote control - AN-CR450 |
| Certificates and Standards | |
| Licenses | RoHS UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 85 % |
