2017 55" TCL U55C7006 Specifications

Brand TCL
Type TV
Size 55" (inches)
Panel SVA
Refresh Rate 60 Hz
Min Response Time 8 ms
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
General Info Type TV
Year 2017
Brand TCL
Model Series C70
Model Number U55C7006
Size 55" (inches)
Panel SVA
Operating System Android 6.0.1 Marshmallow
Display Screen Size Class 55" (inches)
Diagonal Size 54.65 in
138.8 cm
1388 mm
4.55 ft
Screen Width 47.62 in
121 cm
1209.6 mm
3.97 ft
Screen Height 26.79 in
68 cm
680.4 mm
2.23 ft
Display Manufacturer Samsung
Display Type SVA
Display Bit Depth 10 bits (8 bits + FRC)
Frame Rate Control Yes
Max Number of Colors 1073741824
Bits 30
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
Screen Pixel Pitch 0.315 mm
Screen Pixel Density 80 ppi
Screen-to-Body Ratio 91.96 %
Backlight Source Edge LED
DCI P3 83%
Rec.2020 60
sRGB 99 %
Screen Brightness 350 cd/m²
Max Screen Brightness 450 cd/m²
Static Screen Contrast 3500 : 1
Screen Horizontal Viewing Angle 178 °
Screen Vertical Viewing Angle 178 °
Screen Input Lag 26 ms
Display Minimum Response Time 8 ms
HDR HDR10
HLG (Hybrid Log Gamma)
3D No
Size, weight, color Case Depth 2.17 in
5.5 cm
55 mm
0.18 ft
Case Weight 16.4 kg
36 lbs
Case Width with Stand 48.94 in
124.3 cm
1243 mm
4.08 ft
Case Height with Stand 29.72 in
75.5 cm
755 mm
2.48 ft
Case Depth with Stand 8.62 in
21.9 cm
219 mm
0.72 ft
Case Weight with Stand 16.8 kg
37 lbs
Case Color Black
Hardware System on Chip or SoC Mediatek MT5891
CPU ARM Cortex-A53
CPU Cores 4
CPU Frequency 1100
GPU ARM Mali-T860 MP2
GPU Cores 2
GPU Frequency 700
RAM Memory Size 2
Internal Storage 16
TV Tuner Analog (NTSC/PAL/SECAM)
DVB-T2
DVB-S2
DVB-C
DVB-T
DVB-S
Built-in Camera No
Network LAN
Wi-Fi
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11ac (IEEE 802.11ac)
Bluetooth
Wi-Fi Direct
DLNA
Connectivity 1 x Ethernet RJ45
3 x HDMI 2.0 (ARC; CEC; MHL)
1 x S/PDIF
1 x Antenna (RF) (female)
1 x 3.5 mm Audio Out
1 x Satellite In (Main; F-type female)
1 x USB 2.0
1 x CI+
1 x USB 3.0 (max 1 A)
Audio Audio Speakers 2 x 12W
Features OS Android 6.0.1 Marshmallow
Cool Features Picture Noise Reduction
UHD Premium Color Extender
Voice command
Wide Color Gamut
UHD Upscaling
HDCP (High-bandwidth Digital Content Protection) 2.2
Mega Dynamic Contrast
Ergonomics Case Width 48.94 in
124.3 cm
1243 mm
4.08 ft
Case Height 28.35 in
72 cm
720 mm
2.36 ft
Vesa Mount Support Yes
VESA Interface Standard Size 200 x 200
Removable VESA Stand Yes
Height Adjustment No
Landscape or Portrait Pivot Support No
Left or Right Swivel Support No
Forward and Backward Tilt Support No
Frequency and Interpolation Vertical Digital Frequency 60 Hz
Screen Interpolation Technology Picture Performance Index
Screen Interpolation Value 1600
Screen Interpolation Measurement Unit PPI
Power 220V 220 V - 240 V
AC Frequency 50 Hz - 60 Hz
Power Consumption When Device is Off 0.29 W
Average Power Consumption 120 W
Power Consumption in Eco Mode 87 W
Maximum Power Consumption 140 W
Energy Class A+
Accessories Extras Remote control - RC802N1
Certificates and Standards Licenses RoHS
Usage and Storage Requirements Safe Operating Temperature Level 5 °C - 35 °C
41 °F - 95 °F
Safe Operating Humidity Level 20 % - 80 %
Internal Storage Temperature -15 °C - 45 °C
5 °F - 113 °F
Internal Storage Humidity 10 % - 90 %
