| General Info | ||
|---|---|---|
| Model Number | AOC 22P1D | AOC E2060PWDA |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2018 | 2013 |
| Brand | AOC | AOC |
| Model Number | 22P1D | E2060PWDA |
| Display | ||
| Screen Size Class | 22" (inches) | 20" (inches) |
| Diagonal Size | 21.5 in 54.6 cm 546.1 mm 1.79 ft |
19.45 in 49.4 cm 494 mm 1.62 ft |
| Screen Width | 18.77 in 47.7 cm 476.64 mm 1.56 ft |
17.01 in 43.2 cm 432 mm 1.42 ft |
| Screen Height | 10.56 in 26.8 cm 268.11 mm 0.88 ft |
9.44 in 24 cm 239.76 mm 0.79 ft |
| Display Manufacturer | Innolux | |
| Display Type | TN | TN |
| Display Bit Depth | 8 bits (6 bits + FRC) | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 16777216 | 16777216 |
| Bits | 24 | 24 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 1920 x 1080 | 1600 x 900 |
| Screen Pixel Pitch | 0.248 mm | 0.27 mm |
| Screen Pixel Density | 102 ppi | 94 ppi |
| Backlight Source | W-LED | W-LED |
| NTSC 1953 | 72 % | |
| Screen Brightness | 250 cd/m² | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 | 1000 : 1 |
| Dynamic Screen Contrast | 50000000 : 1 | 20000000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° | 170 ° |
| Screen Vertical Viewing Angle | 160 ° | 160 ° |
| Display Minimum Response Time | 2 ms | 5 ms |
| Display Coating | Anti-glare/Matte (3H) | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Width with Stand | 19.86 in 50.4 cm 504.4 mm 1.65 ft |
18.8 in 47.8 cm 477.6 mm 1.57 ft |
| Case Height with Stand | 14.8 in 37.6 cm 376 mm 1.23 ft |
14.88 in 37.8 cm 377.9 mm 1.24 ft |
| Case Depth with Stand | 9.63 in 24.5 cm 244.5 mm 0.8 ft |
|
| Case Weight with Stand | 4.7 kg 10 lbs |
|
| Case Color | Black | Black |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x D-sub 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x DVI-D Dual Link |
1 x 3.5 mm Audio Out 1 x DVI-D 1 x D-sub |
| Audio | ||
| Audio Speakers | 2 x 2W | 2 x 2W |
| Features | ||
| Cool Features | Low Blue Light Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Security lock slot | Anti-theft stand lock slot - Kensington |
| Ergonomics | ||
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | Yes | Yes |
| Height Adjustment Range | 130 mm 13 cm 5.1181 in 0.4265 ft |
130 mm 13 cm 5.1181 in 0.4265 ft |
| Landscape or Portrait Pivot Support | Yes | Yes |
| Left Pivot | 0 ° | 0 ° |
| Right Pivot | 90 ° | 90 ° |
| Left or Right Swivel Support | Yes | Yes |
| Left Swivel | 175 ° | 60 ° |
| Right Swivel | 175 ° | 60 ° |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 3 ° | 5 ° |
| Backward Tilt | 21.5 ° | 15 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 50 Hz - 76 Hz | 50 Hz - 76 Hz |
| Horizontal Digital Frequency | 30 kHz - 83 kHz | 30 kHz - 83 kHz |
| Accessories | ||
| Extras | D-sub cable DVI-D cable HDMI cable |
Audio cable D-sub cable |
| Certificates and Standards | ||
| Licenses | BSMI CE EAC ENERGY STAR FCC Class B |
CE EAC ENERGY STAR Epeat Gold FCC Class B RoHS TCO Certified Displays TÜV/GS |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
|
| Safe Operating Humidity Level | 10 % - 85 % | |
| Internal Storage Temperature | -25 °C - 55 °C -13 °F - 131 °F |
|
| Internal Storage Humidity | 5 % - 93 % | |
| Max Operating Altitude | 5000 | |
| Max Storage Altitude | 12192 |
| AOC 22P1D | AOC E2060PWDA |
