| General Info | ||
|---|---|---|
| Model Number | EIZO EV3285 | AOC U32U1 |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2018 | 2019 |
| Brand | EIZO | AOC |
| Model Series | FlexScan | |
| Model Number | EV3285 | U32U1 |
| Alias | EV3285-BK EV3285-WT |
|
| Display | ||
| Screen Size Class | 32" (inches) | 32" (inches) |
| Diagonal Size | 31.54 in 80.1 cm 801 mm 2.63 ft |
31.54 in 80.1 cm 801 mm 2.63 ft |
| Screen Width | 27.46 in 69.7 cm 697.4 mm 2.29 ft |
27.5 in 69.8 cm 698.4 mm 2.29 ft |
| Screen Height | 15.47 in 39.3 cm 392.85 mm 1.29 ft |
15.47 in 39.3 cm 392.85 mm 1.29 ft |
| Display Type | IPS | IPS |
| Display Bit Depth | 8 bits | 10 bits |
| Frame Rate Control | No | |
| Max Number of Colors | 16777216 | 1073741824 |
| Bits | 24 | 30 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 3840 x 2160 | 3840 x 2160 |
| Screen Pixel Pitch | 0.182 mm | 0.182 mm |
| Screen Pixel Density | 140 ppi | 139 ppi |
| Screen-to-Body Ratio | 91.74 % | 92.23 % |
| Backlight Source | W-LED | W-LED |
| DCI P3 | 75% | |
| sRGB | 100 % | 135 % |
| Adobe RGB 1998 | 75 % | |
| Screen Brightness | 350 cd/m² | 600 cd/m² |
| Static Screen Contrast | 1300 : 1 | 1300 : 1 |
| Dynamic Screen Contrast | 50000000 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Screen Input Lag | 35 ms | |
| Display Minimum Response Time | 5 ms | 5 ms |
| Display Average Response Time | 8 ms | |
| Display Maximum Response Time | 15 ms | |
| HDR | HDR DisplayHDR 600 |
|
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 2.03 in 5.2 cm 51.5 mm 0.17 ft |
2.96 in 7.5 cm 75.07 mm 0.25 ft |
| Case Weight | 7.6 kg 17 lbs |
|
| Case Width with Stand | 28.24 in 71.7 cm 717.4 mm 2.35 ft |
28.27 in 71.8 cm 718.15 mm 2.36 ft |
| Case Height with Stand | 16.82 in 42.7 cm 427.3 mm 1.4 ft |
|
| Case Depth with Stand | 9.06 in 23 cm 230 mm 0.75 ft |
10.93 in 27.8 cm 277.5 mm 0.91 ft |
| Case Weight with Stand | 11 kg 24 lbs |
8 kg 18 lbs |
| Case Color | Black, White | Black, Silver |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 2 x HDMI 1 x DisplayPort 1.2 1 x 3.5 mm Audio Out 2 x USB 2.0 (downstream) 1 x USB 3.1 (Type-C) |
1 x HDMI 1.4 1 x HDMI 2.0 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x DisplayPort 1.2 1 x USB (Type-C - 65 W) 4 x USB 3.1 (downstream) |
| Audio | ||
| Audio Speakers | 2 x 1W | 2 x 2W |
| Features | ||
| Cool Features | HDCP (High-bandwidth Digital Content Protection) Light sensor Low Blue Light EcoView Flicker-free technology |
Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Anti-theft stand lock slot - Kensington | |
| Ergonomics | ||
| Case Width | 28.24 in 71.7 cm 717.4 mm 2.35 ft |
28.27 in 71.8 cm 718.15 mm 2.36 ft |
| Case Height | 16.39 in 41.6 cm 416.3 mm 1.37 ft |
16.31 in 41.4 cm 414.25 mm 1.36 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | Yes | Yes |
| Height Adjustment Range | 149 mm 14.9 cm 5.8661 in 0.4888 ft |
120 mm 12 cm 4.7244 in 0.3937 ft |
| Landscape or Portrait Pivot Support | No | Yes |
| Left Pivot | 0 ° | |
| Right Pivot | 90 ° | |
| Left or Right Swivel Support | Yes | Yes |
| Left Swivel | 172 ° | 40 ° |
| Right Swivel | 172 ° | 40 ° |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 5 ° | 3.5 ° |
| Backward Tilt | 35 ° | 18.5 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 29 Hz - 71 Hz | 23 Hz - 60 Hz |
| Horizontal Digital Frequency | 31 kHz - 135 kHz | 30 kHz - 160 kHz |
| Accessories | ||
| Extras | DisplayPort cable HDMI cable USB Type-C cable |
DisplayPort cable HDMI cable USB cable |
| Certificates and Standards | ||
| Licenses | CB CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Displays 7.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
CCC CE EAC ENERGY STAR FCC Class B RoHS TCO Certified Displays 7.0 TÜV/Ergonomics TÜV/GS |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 35 °C 32 °F - 95 °F |
0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 20 % - 80 % | 10 % - 85 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
-20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 10 % - 90 % | 5 % - 90 % |
| Max Operating Altitude | 3657.6 | |
| Max Storage Altitude | 12192 |
| EIZO EV3285 | AOC U32U1 |
