| General Info | ||
|---|---|---|
| Model Number | Lenovo ThinkVision D24-10 | AOC 24P1 |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2018 | 2018 |
| Brand | Lenovo | AOC |
| Model Number | ThinkVision D24-10 | 24P1 |
| Alias | 65E2KAC1EU | |
| Display | ||
| Screen Size Class | 24" (inches) | 24" (inches) |
| Diagonal Size | 23.58 in 59.9 cm 599 mm 1.97 ft |
23.78 in 60.4 cm 604 mm 1.98 ft |
| Screen Width | 20.52 in 52.1 cm 521.28 mm 1.71 ft |
20.75 in 52.7 cm 527.04 mm 1.73 ft |
| Screen Height | 11.54 in 29.3 cm 293.22 mm 0.96 ft |
11.67 in 29.6 cm 296.46 mm 0.97 ft |
| Display Type | TN | IPS |
| Display Bit Depth | 8 bits (6 bits + FRC) | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 16777216 | 16777216 |
| Bits | 24 | 24 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 1920 x 1080 | 1920 x 1080 |
| Screen Pixel Pitch | 0.272 mm | 0.275 mm |
| Screen Pixel Density | 93 ppi | 92 ppi |
| Screen-to-Body Ratio | 80.04 % | 89.01 % |
| Backlight Source | W-LED | W-LED |
| NTSC 1953 | 72 % | |
| Screen Brightness | 250 cd/m² | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 | 1000 : 1 |
| Dynamic Screen Contrast | 3000000 : 1 | 50000000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° | 178 ° |
| Screen Vertical Viewing Angle | 160 ° | 178 ° |
| Display Minimum Response Time | 1 ms | 5 ms |
| Display Average Response Time | 5 ms | |
| Display Coating | Anti-glare/Matte | Anti-glare/Matte (3H) |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 1.99 in 5.1 cm 50.5 mm 0.17 ft |
1.94 in 4.9 cm 49.4 mm 0.16 ft |
| Case Weight | 3.29 kg 7 lbs |
2.8 kg 6 lbs |
| Case Width with Stand | 22.28 in 56.6 cm 566 mm 1.86 ft |
21.22 in 53.9 cm 539.1 mm 1.77 ft |
| Case Height with Stand | 15.55 in 39.5 cm 395.05 mm 1.3 ft |
14.52 in 36.9 cm 368.9 mm 1.21 ft |
| Case Depth with Stand | 7.47 in 19 cm 189.8 mm 0.62 ft |
7.97 in 20.3 cm 202.5 mm 0.66 ft |
| Case Weight with Stand | 4.6 kg 10 lbs |
|
| Case Color | Black | Black |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x D-sub |
1 x DisplayPort 1.2 1 x DVI-D Dual Link 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x D-sub 4 x USB 3.0 (downstream) 1 x HDMI 1.4 |
| Audio | ||
| Audio Speakers | 2 x 2W | |
| Features | ||
| Cool Features | HDCP (High-bandwidth Digital Content Protection) Blue Light Filter DDC/CI |
Low Blue Light Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Anti-theft stand lock slot - Kensington | Security lock slot |
| Ergonomics | ||
| Case Width | 22.28 in 56.6 cm 566 mm 1.86 ft |
21.22 in 53.9 cm 539.1 mm 1.77 ft |
| Case Height | 13.28 in 33.7 cm 337.4 mm 1.11 ft |
12.82 in 32.6 cm 325.6 mm 1.07 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | Yes |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
|
| Landscape or Portrait Pivot Support | No | Yes |
| Left Pivot | 0 ° | |
| Right Pivot | 90 ° | |
| Left or Right Swivel Support | No | Yes |
| Left Swivel | 175 ° | |
| Right Swivel | 175 ° | |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 4 ° | 3 ° |
| Backward Tilt | 22 ° | 22.5 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 50 Hz - 75 Hz | 50 Hz - 76 Hz |
| Horizontal Digital Frequency | 30 kHz - 83 kHz | 30 kHz - 83 kHz |
| Accessories | ||
| Extras | D-sub cable | D-sub cable DVI-D cable HDMI cable |
| Certificates and Standards | ||
| Licenses | BSMI C-Tick CCC CE CECP ENERGY STAR 7.0 FCC Class B KC RoHS TCO Certified Display 7.0 TCO Edge 2.0 TÜV/GS VCCI WHQL (Windows 10; Windows 8.1; Windows 8; Windows 7) |
BSMI CE EAC ENERGY STAR FCC Class B |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 45 °C 32 °F - 113 °F |
0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 80 % | 10 % - 85 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
-25 °C - 55 °C -13 °F - 131 °F |
| Internal Storage Humidity | 5 % - 95 % | 5 % - 93 % |
| Max Operating Altitude | 5000 | 5000 |
| Max Storage Altitude | 12192 | 12192 |
| Lenovo ThinkVision D24-10 | AOC 24P1 |
