| General Info | ||
|---|---|---|
| Model Number | TCL 75S546 | Vizio V705-H13 |
|
|
|
| Price | ||
| Type | TV | TV |
| Year | 2021 | 2020 |
| Brand | TCL | Vizio |
| Model Series | S546 | V |
| Model Number | 75S546 | V705-H13 |
| Display | ||
| Screen Size Class | 75" (inches) | 70" (inches) |
| Diagonal Size | 74.53 in 189.3 cm 1893 mm 6.21 ft |
69.5 in 176.5 cm 1765.3 mm 5.79 ft |
| Screen Width | 64.97 in 165 cm 1650.24 mm 5.41 ft |
60.59 in 153.9 cm 1538.88 mm 5.05 ft |
| Screen Height | 36.55 in 92.8 cm 928.26 mm 3.05 ft |
34.08 in 86.6 cm 865.62 mm 2.84 ft |
| Display Type | VA | VA |
| Display Bit Depth | 10 bits (8 bits + FRC) | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes | Yes |
| Max Number of Colors | 1073741824 | 1073741824 |
| Bits | 30 | 30 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 3840 x 2160 | 3840 x 2160 |
| Screen Pixel Pitch | 0.43 mm | 0.401 mm |
| Screen Pixel Density | 59 ppi | 63 ppi |
| Screen-to-Body Ratio | 95.21 % | 93.59 % |
| Backlight Source | Direct LED (Full-Array Local Dimming) | Direct LED (Full-Array Local Dimming) |
| Dynamic Screen Contrast | 200000 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | 176 ° |
| Screen Vertical Viewing Angle | 178 ° | 176 ° |
| Display Coating | Glossy | |
| HDR | HDR10 HLG (Hybrid Log Gamma) Dolby Vision HDR10+ |
HDR10 HLG (Hybrid Log Gamma) Dolby Vision HDR10+ |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 3.9 in 9.9 cm 99 mm 0.32 ft |
2.7 in 6.9 cm 68.58 mm 0.23 ft |
| Case Weight | 30.62 kg 67 lbs |
23.9 kg 53 lbs |
| Case Width with Stand | 65.8 in 167.1 cm 1671.32 mm 5.48 ft |
61.8 in 157 cm 1569.72 mm 5.15 ft |
| Case Height with Stand | 40.4 in 102.6 cm 1026.16 mm 3.37 ft |
38.4 in 97.5 cm 975.36 mm 3.2 ft |
| Case Depth with Stand | 14.3 in 36.3 cm 363.22 mm 1.19 ft |
13 in 33 cm 330.2 mm 1.08 ft |
| Case Weight with Stand | 31.3 kg 69 lbs |
24.4 kg 54 lbs |
| Case Color | Black | Black |
| Hardware | ||
| CPU Cores | 4 | 4 |
| GPU Cores | 2 | 4 |
| TV Tuner | Analog (NTSC/PAL/SECAM) ATSC Clear QAM |
Analog (NTSC/PAL/SECAM) ATSC Clear QAM |
| Built-in Camera | No | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi Direct |
LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi Direct |
| Connectivity | 3 x HDMI 2.0 1 x Cable/Antenna In (F-type female) 1 x S/PDIF 1 x 3.5 mm Audio Out 1 x AV Composite In 3.5 mm jack 1 x USB 2.0 1 x Ethernet RJ45 |
3 x HDMI 2.1 (CEC) 1 x Satellite In (Main; F-type female) 1 x Optical Audio Out 1 x RCA Audio Out (L/R) 1 x USB 2.0 1 x Ethernet RJ45 |
| Audio | ||
| Audio Speakers | 2 x 15W | 2 x 10W |
| Features | ||
| OS | Google TV | SmartCast 4.0 |
| Cool Features | YouTube Apple TV+ Smart Contrast Smart 4K Upscaling Smart HDR Auto Game Mode HDR Pro Pack Chromecast built-in Easy Voice Control Quantum Dot Color Netflix V-Chip Disney+ Contrast Control Zones technology Alexa Prime Video FullView Edge-to-Edge Glass Design Apple AirPlay Google Assistant |
IQ Active 4K HDR Processor Light sensor V-Gaming Engine Spatial Scaling Engine Apple AirPlay 2 Chromecast built-in |
| Ergonomics | ||
| Case Width | 65.8 in 167.1 cm 1671.32 mm 5.48 ft |
61.8 in 157 cm 1569.72 mm 5.15 ft |
| Case Height | 37.9 in 96.3 cm 962.66 mm 3.16 ft |
35.7 in 90.7 cm 906.78 mm 2.98 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 400 x 300 | 400 x 200 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | No | No |
| Landscape or Portrait Pivot Support | No | No |
| Left or Right Swivel Support | No | No |
| Forward and Backward Tilt Support | No | No |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 48 Hz - 60 Hz | 50 Hz / 60 Hz |
| Screen Interpolation Technology | Natural Motion | Dynamic Motion Rate |
| Screen Interpolation Value | 240 | 120 |
| Screen Interpolation Measurement Unit | NM | DMR |
| Accessories | ||
| Extras | Voice-Enabled Remote Control - RC902N | Remote control - XRT140 |
| Certificates and Standards | ||
| Licenses | ENERGY STAR FCC Class B UL/cUL |
|
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
|
| Safe Operating Humidity Level | 20 % - 80 % | |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
|
| Internal Storage Humidity | 10 % - 90 % |
| TCL 75S546 | Vizio V705-H13 |
