| Brand | AOC |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | MVA |
| Refresh Rate | 76 Hz |
| Min Response Time | 8 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2018 |
| Brand | AOC |
| Model Number | 22P1 |
| Size | 22" (inches) |
| Panel | MVA |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 21.5 in 54.6 cm 546.1 mm 1.79 ft |
| Screen Width | 18.74 in 47.6 cm 476.064 mm 1.56 ft |
| Screen Height | 10.54 in 26.8 cm 267.786 mm 0.88 ft |
| Display Type | MVA |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.248 mm |
| Screen Pixel Density | 102 ppi |
| Backlight Source | W-LED |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 3000 : 1 |
| Dynamic Screen Contrast | 50000000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 8 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Width with Stand | 19.86 in 50.4 cm 504.4 mm 1.65 ft |
| Case Height with Stand | 14.8 in 37.6 cm 376 mm 1.23 ft |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x DisplayPort 1.2 1 x DVI-D Dual Link 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x D-sub 4 x USB 3.0 (downstream) 1 x HDMI 1.4 |
| Audio | |
| Audio Speakers | 2 x 2W |
| Features | |
| Cool Features | Low Blue Light Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Security lock slot |
| Ergonomics | |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 130 mm 13 cm 5.1181 in 0.4265 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 175 ° |
| Right Swivel | 175 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 3 ° |
| Backward Tilt | 21.5 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 50 Hz - 76 Hz |
| Horizontal Digital Frequency | 30 kHz - 83 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 20 W |
| Accessories | |
| Extras | D-sub cable DVI-D cable HDMI cable |
| Certificates and Standards | |
| Licenses | BSMI CE EAC ENERGY STAR FCC Class B |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 85 % |
| Internal Storage Temperature | -25 °C - 55 °C -13 °F - 131 °F |
| Internal Storage Humidity | 5 % - 93 % |
| Max Operating Altitude | 5000 |
| Max Storage Altitude | 12192 |
