| Brand | AOC |
| Type | Monitor |
| Size | 34" (inches) |
| Panel | AH-IPS |
| Refresh Rate | 80 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 21:9 |
| Screen Resolution | 3440 x 1440 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2014 |
| Brand | AOC |
| Model Number | U3477PQU |
| Size | 34" (inches) |
| Panel | AH-IPS |
| Display | |
| Screen Size Class | 34" (inches) |
| Diagonal Size | 34 in 86.4 cm 863.6 mm 2.83 ft |
| Screen Width | 31.49 in 80 cm 799.8 mm 2.62 ft |
| Screen Height | 13.18 in 33.5 cm 334.8 mm 1.1 ft |
| Display Manufacturer | LG Display |
| Display Type | AH-IPS |
| Display Bit Depth | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 21:9 |
| Screen Resolution | 3440 x 1440 |
| Screen Pixel Pitch | 0.233 mm |
| Screen Pixel Density | 109 ppi |
| Backlight Source | W-LED |
| sRGB | 97 % |
| Adobe RGB 1998 | 71 % |
| NTSC 1953 | 72 % |
| Screen Brightness | 320 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Dynamic Screen Contrast | 80000000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Screen Input Lag | 20 ms |
| Display Minimum Response Time | 5 ms |
| Display Average Response Time | 14 ms |
| 3D | No |
| Size, weight, color | |
| Case Width with Stand | 32.6 in 82.8 cm 828 mm 2.72 ft |
| Case Height with Stand | 24.59 in 62.5 cm 624.5 mm 2.05 ft |
| Case Depth with Stand | 9.02 in 22.9 cm 229.2 mm 0.75 ft |
| Case Weight with Stand | 10 kg 22 lbs |
| Case Color | Black, Silver |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x USB 3.0 (upstream) 1 x HDMI 2.0 (MHL) 1 x DVI-D Dual Link 1 x 3.5 mm Audio In 1 x D-sub 1 x DisplayPort 1.2 2 x USB 2.0 (downstream) 1 x 3.5 mm Audio Out 2 x USB 3.0 (downstream) |
| Audio | |
| Audio Speakers | 2 x 3W |
| Features | |
| Cool Features | Picture-by-Picture Picture-in-Picture Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Extra Features | Anti-theft stand lock slot - Kensington |
| Ergonomics | |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 130 mm 13 cm 5.1181 in 0.4265 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 165 ° |
| Right Swivel | 165 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 24 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 23 Hz - 80 Hz |
| Horizontal Digital Frequency | 30 kHz - 160 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.5 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 70 W |
| Power Consumption in Eco Mode | 47.54 W |
| Accessories | |
| Extras | Audio cable D-sub cable DisplayPort cable HDMI cable USB 3.0 upstream cable |
| Certificates and Standards | |
| Licenses | CCC CE EAC ENERGY STAR 6.0 Epeat Silver GOST-R RoHS TCO Certified Displays 6.0 TÜV/GS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 85 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 90 % |
| Max Operating Altitude | 3657.6 |
| Max Storage Altitude | 12192 |
