| Brand | EIZO |
| Type | Monitor |
| Size | 27" (inches) |
| Panel | IPS |
| Refresh Rate | 61 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2020 |
| Brand | EIZO |
| Model Series | ColorEdge |
| Model Number | CS2740-X |
| Alias | CS2740X CS2740-XBK |
| Size | 27" (inches) |
| Panel | IPS |
| Display | |
| Screen Size Class | 27" (inches) |
| Diagonal Size | 26.93 in 68.4 cm 684.02 mm 2.24 ft |
| Screen Width | 23.47 in 59.6 cm 596.2 mm 1.96 ft |
| Screen Height | 13.2 in 33.5 cm 335.3 mm 1.1 ft |
| Display Type | IPS |
| Display Bit Depth | 10 bits |
| Frame Rate Control | No |
| Lut | 16 bits |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.155 mm |
| Screen Pixel Density | 163 ppi |
| Screen-to-Body Ratio | 82.85 % |
| Backlight Source | W-LED |
| DCI P3 | 91% |
| Adobe RGB 1998 | 99 % |
| Screen Brightness | 350 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Average Response Time | 10 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.95 in 7.5 cm 75 mm 0.25 ft |
| Case Weight | 6.7 kg 15 lbs |
| Case Width with Stand | 25.12 in 63.8 cm 638 mm 2.09 ft |
| Case Height with Stand | 15.91 in 40.4 cm 404.1 mm 1.33 ft |
| Case Depth with Stand | 10.43 in 26.5 cm 265 mm 0.87 ft |
| Case Weight with Stand | 10.3 kg 23 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 2 x USB 3.1 (Type-A; Gen 1; downstream) 1 x USB 3.1 (Type-C; Gen 1; DisplayPort; HDCP 1.3; 60W) 1 x DisplayPort 1.2 (HDCP 1.3) 1 x HDMI 1.4 (HDCP 2.2) 2 x USB 2.0 (Type-A; downstream) 1 x USB 3.1 (Type-B; Gen 1; upstream) |
| Audio | |
| Features | |
| Cool Features | Adobe RGB sRGB DUE (Digital Uniformity Equalizer) Flicker-free technology Calibration (CAL)) ColorNavigator 7 Color mode (User |
| Ergonomics | |
| Case Width | 25.12 in 63.8 cm 638 mm 2.09 ft |
| Case Height | 14.89 in 37.8 cm 378.2 mm 1.24 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 155 mm 15.5 cm 6.1024 in 0.5085 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 172 ° |
| Right Swivel | 172 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 23 Hz - 61 Hz |
| Horizontal Digital Frequency | 15 kHz - 137 kHz |
| Screen Interpolation Measurement Unit | NULL |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 1 W |
| Power Consumption in Sleep Mode | 1 W |
| Average Power Consumption | 36 W |
| Maximum Power Consumption | 168 W |
| Accessories | |
| Extras | DisplayPort cable HDMI cable USB Type-C cable |
| Certificates and Standards | |
| Licenses | CB TUV / S PSE VCCI-B |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 35 °C 32 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 10 % - 90 % |
