| Brand | EIZO |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | TN |
| Refresh Rate | 61 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1650 x 1050 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2012 |
| Brand | EIZO |
| Model Series | FlexScan |
| Model Number | EV2216W |
| Size | 22" (inches) |
| Panel | TN |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 22 in 55.9 cm 558.8 mm 1.83 ft |
| Screen Width | 18.65 in 47.4 cm 473.76 mm 1.55 ft |
| Screen Height | 11.66 in 29.6 cm 296.1 mm 0.97 ft |
| Display Type | TN |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1650 x 1050 |
| Screen Pixel Pitch | 0.282 mm |
| Screen Pixel Density | 88 ppi |
| Screen-to-Body Ratio | 85.93 % |
| Backlight Source | W-LED |
| NTSC 1953 | 72 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° |
| Screen Vertical Viewing Angle | 160 ° |
| Display Minimum Response Time | 5 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.13 in 5.4 cm 54 mm 0.18 ft |
| Case Weight | 3.3 kg 7 lbs |
| Case Width with Stand | 19.69 in 50 cm 500 mm 1.64 ft |
| Case Height with Stand | 14.49 in 36.8 cm 368 mm 1.21 ft |
| Case Depth with Stand | 9.17 in 23.3 cm 233 mm 0.76 ft |
| Case Weight with Stand | 5.6 kg 12 lbs |
| Case Color | Black, Gray |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x DisplayPort 1 x DVI-D Dual Link 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x D-sub 2 x USB 2.0 (downstream) 1 x USB 2.0 (upstream) |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | Light sensor Paper mode Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Case Width | 19.69 in 50 cm 500 mm 1.64 ft |
| Case Height | 12.85 in 32.7 cm 326.5 mm 1.07 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 140 mm 14 cm 5.5118 in 0.4593 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 172 ° |
| Right Swivel | 172 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 59 Hz - 61 Hz |
| Horizontal Digital Frequency | 31 kHz - 67.5 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.3 W |
| Power Consumption in Eco Mode | 12 W |
| Maximum Power Consumption | 39 W |
| Accessories | |
| Extras | DisplayPort cable DVI-D cable |
| Certificates and Standards | |
| Licenses | CB CCC CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Certified Displays 6.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
