| Brand | EIZO |
| Type | Monitor |
| Size | 24" (inches) |
| Panel | IPS |
| Refresh Rate | 61 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1920 x 1200 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2018 |
| Brand | EIZO |
| Model Series | FlexScan |
| Model Number | EV2430 |
| Alias | EV2430-BK EV2430-GY |
| Size | 24" (inches) |
| Panel | IPS |
| Display | |
| Screen Size Class | 24" (inches) |
| Diagonal Size | 24.06 in 61.1 cm 611 mm 2 ft |
| Screen Width | 20.41 in 51.8 cm 518.4 mm 1.7 ft |
| Screen Height | 12.76 in 32.4 cm 324 mm 1.06 ft |
| Display Type | IPS |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1920 x 1200 |
| Screen Pixel Pitch | 0.27 mm |
| Screen Pixel Density | 94 ppi |
| Screen-to-Body Ratio | 84.92 % |
| Backlight Source | W-LED |
| Screen Brightness | 300 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 5 ms |
| Display Average Response Time | 14 ms |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.24 in 5.7 cm 56.9 mm 0.19 ft |
| Case Weight | 4.3 kg 9 lbs |
| Case Width with Stand | 21.75 in 55.3 cm 552.5 mm 1.81 ft |
| Case Height with Stand | 14.49 in 36.8 cm 368 mm 1.21 ft |
| Case Depth with Stand | 9.17 in 23.3 cm 233 mm 0.76 ft |
| Case Weight with Stand | 6.7 kg 15 lbs |
| Case Color | Black, Gray |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x DisplayPort 1.2 1 x DVI-D Dual Link 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x D-sub 2 x USB 2.0 (downstream) 1 x USB 2.0 (upstream) |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | HDCP (High-bandwidth Digital Content Protection) Light sensor Low Blue Light EcoView Flicker-free technology |
| Ergonomics | |
| Case Width | 21.75 in 55.3 cm 552.5 mm 1.81 ft |
| Case Height | 14.09 in 35.8 cm 358 mm 1.17 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 131 mm 13.1 cm 5.1575 in 0.4298 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 90 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 172 ° |
| Right Swivel | 172 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 59 Hz - 61 Hz |
| Horizontal Digital Frequency | 55 kHz - 61 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.5 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Power Consumption in Eco Mode | 12 W |
| Maximum Power Consumption | 36 W |
| Accessories | |
| Extras | DisplayPort cable DVI-D cable |
| Certificates and Standards | |
| Licenses | CB CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Displays 7.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 35 °C 32 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 10 % - 90 % |
