| Brand | EIZO |
| Type | Monitor |
| Size | 23" (inches) |
| Panel | PLS |
| Refresh Rate | 61 Hz |
| Min Response Time | 6 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2012 |
| Brand | EIZO |
| Model Number | FlexScan EV2336W |
| Size | 23" (inches) |
| Panel | PLS |
| Display | |
| Screen Size Class | 23" (inches) |
| Diagonal Size | 23 in 58.4 cm 584.2 mm 1.92 ft |
| Screen Width | 20.07 in 51 cm 509.76 mm 1.67 ft |
| Screen Height | 11.29 in 28.7 cm 286.74 mm 0.94 ft |
| Display Manufacturer | Samsung |
| Display Type | PLS |
| Display Bit Depth | 8 bits |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.266 mm |
| Screen Pixel Density | 95 ppi |
| Screen-to-Body Ratio | 85.25 % |
| Backlight Source | W-LED |
| Screen Brightness | 300 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° |
| Screen Vertical Viewing Angle | 160 ° |
| Screen Input Lag | 1 ms |
| Display Minimum Response Time | 6 ms |
| Display Average Response Time | 13 ms |
| Display Maximum Response Time | 16 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.2 in 5.6 cm 56 mm 0.18 ft |
| Case Weight | 3.7 kg 8 lbs |
| Case Width with Stand | 21.26 in 54 cm 540 mm 1.77 ft |
| Case Height with Stand | 14.49 in 36.8 cm 368 mm 1.21 ft |
| Case Depth with Stand | 9.17 in 23.3 cm 233 mm 0.76 ft |
| Case Weight with Stand | 6.1 kg 13 lbs |
| Case Color | Black, Gray |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x DisplayPort 1 x DVI-D Dual Link 1 x D-sub 2 x USB 2.0 (downstream) 1 x USB 2.0 (upstream) |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | Light sensor Paper mode Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Case Width | 21.26 in 54 cm 540 mm 1.77 ft |
| Case Height | 12.5 in 31.8 cm 317.5 mm 1.04 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 140 mm 14 cm 5.5118 in 0.4593 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 172 ° |
| Right Swivel | 172 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 59 Hz - 61 Hz |
| Horizontal Digital Frequency | 31 kHz - 68 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Electric Power in Amperes | 0.8 A |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 24 W |
| Power Consumption in Eco Mode | 16 W |
| Maximum Power Consumption | 47 W |
| Accessories | |
| Extras | DisplayPort cable DVI-D cable |
| Certificates and Standards | |
| Licenses | CB CCC CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Certified Displays 6.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
