| Brand | NEC |
| Type | Monitor |
| Size | 20" (inches) |
| Panel | S-IPS |
| Refresh Rate | 75 Hz |
| Min Response Time | 6 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1680 x 1050 |
| General Info | Type | Monitor |
|---|---|---|
| Year | 2005 | |
| Brand | NEC | |
| Model Number | MultiSync 20WGX2 | |
| Alias | LCD20WGX2 | |
| Size | 20" (inches) | |
| Panel | S-IPS | |
| Display | Screen Size Class | 20" (inches) |
| Diagonal Size | 20.08 in 51 cm 510 mm 1.67 ft |
|
| Screen Width | 17.06 in 43.3 cm 433.44 mm 1.42 ft |
|
| Screen Height | 10.67 in 27.1 cm 270.9 mm 0.89 ft |
|
| Display Manufacturer | LG Display | |
| Display Type | S-IPS | |
| Display Bit Depth | 8 bits | |
| Frame Rate Control | No | |
| Max Number of Colors | 16777216 | |
| Bits | 24 | |
| Screen Aspect Ratio | 16:10 | |
| Screen Resolution | 1680 x 1050 | |
| Screen Pixel Pitch | 0.258 mm | |
| Screen Pixel Density | 98 ppi | |
| Backlight Source | CCFL | |
| Screen Brightness | 470 cd/m² | |
| Static Screen Contrast | 700 : 1 | |
| Dynamic Screen Contrast | 1600 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | |
| Screen Vertical Viewing Angle | 178 ° | |
| Screen Input Lag | 15 ms | |
| Display Minimum Response Time | 6 ms | |
| Display Average Response Time | 12 ms | |
| Display Coating | Glossy | |
| 3D | No | |
| Size, weight, color | Case Width with Stand | 18.56 in 47.1 cm 471.4 mm 1.55 ft |
| Case Height with Stand | 15.41 in 39.2 cm 391.5 mm 1.28 ft |
|
| Case Depth with Stand | 7.99 in 20.3 cm 203 mm 0.67 ft |
|
| Case Weight with Stand | 6.3 kg 14 lbs |
|
| Case Color | Black, Silver | |
| Hardware | Built-in Camera | No |
| Connectivity | 1 x DVI-D Dual Link 1 x D-sub 4 x USB 2.0 (downstream) 1 x USB 2.0 (upstream) |
|
| Ergonomics | Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 | |
| Removable VESA Stand | Yes | |
| Height Adjustment | No | |
| Left or Right Swivel Support | Yes | |
| Left Swivel | 180 ° | |
| Right Swivel | 180 ° | |
| Forward and Backward Tilt Support | Yes | |
| Forward Tilt | 5 ° | |
| Backward Tilt | 30 ° | |
| Frequency and Interpolation | Vertical Digital Frequency | 56 Hz - 75 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 81.1 kHz | |
| Power | 110V | 100 V - 120 V |
| 220V | 220 V - 240 V | |
| AC Frequency | 50 Hz - 60 Hz | |
| Electric Power in Amperes | 1.05 A | |
| Power Consumption When Device is Off | 0.5 W | |
| Power Consumption in Sleep Mode | 1.5 W | |
| Average Power Consumption | 67 W | |
| Maximum Power Consumption | 84 W | |
| Accessories | Extras | D-sub cable DVI-D cable USB cable |
| Certificates and Standards | Licenses | CE CSA FCC Class B ISO 13406-2 MPR 2 MPR 3 PCT/Gost GEEA Energy label RoHS TCO 03 TÜV/Ergonomics TÜV/GS |
| Usage and Storage Requirements | Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 30 % - 80 % | |
| Internal Storage Temperature | -10 °C - 60 °C 14 °F - 140 °F |
|
| Internal Storage Humidity | 10 % - 85 % | |
| Max Operating Altitude | 12000 | |
| Max Storage Altitude | 40000 |
