| Brand | NEC |
| Type | Monitor |
| Size | 17" (inches) |
| Panel | TN |
| Refresh Rate | 76 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 5:4 |
| Screen Resolution | 1280 x 1024 |
| Price | 172.24 |
| General Info | Type | Monitor |
|---|---|---|
| Year | 2014 | |
| Brand | NEC | |
| Model Number | MultiSync E171M | |
| Alias | E171M-BK E171M-WH |
|
| Size | 17" (inches) | |
| Panel | TN | |
| Display | Screen Size Class | 17" (inches) |
| Diagonal Size | 17 in 43.2 cm 431.8 mm 1.42 ft |
|
| Screen Width | 13.3 in 33.8 cm 337.92 mm 1.11 ft |
|
| Screen Height | 10.64 in 27 cm 270.336 mm 0.89 ft |
|
| Display Type | TN | |
| Display Bit Depth | 8 bits (6 bits + FRC) | |
| Frame Rate Control | Yes | |
| Max Number of Colors | 16777216 | |
| Bits | 24 | |
| Screen Aspect Ratio | 5:4 | |
| Screen Resolution | 1280 x 1024 | |
| Screen Pixel Pitch | 0.264 mm | |
| Screen Pixel Density | 96 ppi | |
| Screen-to-Body Ratio | 77.45 % | |
| Backlight Source | W-LED | |
| Screen Brightness | 250 cd/m² | |
| Static Screen Contrast | 1000 : 1 | |
| Screen Horizontal Viewing Angle | 170 ° | |
| Screen Vertical Viewing Angle | 170 ° | |
| Display Minimum Response Time | 5 ms | |
| Display Coating | Anti-glare/Matte (3H) | |
| 3D | No | |
| Size, weight, color | Case Depth | 2.4 in 6.1 cm 61 mm 0.2 ft |
| Case Weight | 3 kg 7 lbs |
|
| Case Width with Stand | 14.49 in 36.8 cm 368 mm 1.21 ft |
|
| Case Height with Stand | 14.11 in 35.9 cm 358.5 mm 1.18 ft |
|
| Case Depth with Stand | 9.06 in 23 cm 230 mm 0.75 ft |
|
| Case Weight with Stand | 4.2 kg 9 lbs |
|
| Case Color | Black, White | |
| Hardware | Built-in Camera | No |
| Connectivity | 1 x 3.5 mm Audio In 1 x 3.5 mm Audio Out 1 x DVI-D Dual Link 1 x D-sub |
|
| Audio | Audio Speakers | 2 x 1W |
| Features | Cool Features | HDCP (High-bandwidth Digital Content Protection) NaViSet software XtraView Carbon Footprint Meter Eco Modes |
| Ergonomics | Case Width | 14.49 in 36.8 cm 368 mm 1.21 ft |
| Case Height | 12.62 in 32.1 cm 320.5 mm 1.05 ft |
|
| Vesa Mount Support | Yes | |
| VESA Interface Standard Size | 100 x 100 | |
| Removable VESA Stand | Yes | |
| Height Adjustment | Yes | |
| Height Adjustment Range | 50 mm 5 cm 1.9685 in 0.164 ft |
|
| Landscape or Portrait Pivot Support | No | |
| Left or Right Swivel Support | No | |
| Forward and Backward Tilt Support | Yes | |
| Forward Tilt | 5 ° | |
| Backward Tilt | 20 ° | |
| Frequency and Interpolation | Vertical Digital Frequency | 56 Hz - 76 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 81.1 kHz | |
| Power | 110V | 100 V - 120 V |
| 220V | 220 V - 240 V | |
| AC Frequency | 50 Hz - 60 Hz | |
| Electric Power in Amperes | 1 A | |
| Power Consumption When Device is Off | 0.33 W | |
| Average Power Consumption | 12 W | |
| Power Consumption in Eco Mode | 9 W | |
| Maximum Power Consumption | 15 W | |
| Energy Class | A | |
| Accessories | Extras | Audio cable D-sub cable |
| Certificates and Standards | Licenses | CE EAC ENERGY STAR 6.0 ErP FCC Class B ISO 9241-307 MPR III PCT/Gost RoHS TCO Certified Displays 6.0 TÜV/Ergonomics UL/cUL |
| Usage and Storage Requirements | Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | |
| Internal Storage Temperature | -10 °C - 60 °C 14 °F - 140 °F |
|
| Internal Storage Humidity | 10 % - 85 % | |
| Max Operating Altitude | 2000 | |
| Max Storage Altitude | 12192 |
