| Brand | NEC |
| Type | Monitor |
| Size | 24" (inches) |
| Panel | AH-IPS |
| Refresh Rate | 85 Hz |
| Min Response Time | 8 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 1920 x 1200 |
| General Info | Type | Monitor |
|---|---|---|
| Year | 2017 | |
| Brand | NEC | |
| Model Number | MultiSync PA243W | |
| Alias | PA243W-BK | |
| Size | 24" (inches) | |
| Panel | AH-IPS | |
| Display | Screen Size Class | 24" (inches) |
| Diagonal Size | 24.06 in 61.1 cm 611 mm 2 ft |
|
| Screen Width | 20.33 in 51.6 cm 516.4 mm 1.69 ft |
|
| Screen Height | 12.76 in 32.4 cm 324 mm 1.06 ft |
|
| Display Type | AH-IPS | |
| Display Bit Depth | 10 bits | |
| Frame Rate Control | No | |
| Lut | 3D LUT 14 bits |
|
| Max Number of Colors | 1073741824 | |
| Bits | 30 | |
| Screen Aspect Ratio | 16:10 | |
| Screen Resolution | 1920 x 1200 | |
| Screen Pixel Pitch | 0.27 mm | |
| Screen Pixel Density | 94 ppi | |
| Screen-to-Body Ratio | 83.14 % | |
| Backlight Source | W-LED | |
| DCI P3 | 96.9% | |
| Rec.2020 | 80 | |
| sRGB | 100 % | |
| Adobe RGB 1998 | 99.6 % | |
| NTSC 1953 | 72 % | |
| Screen Brightness | 350 cd/m² | |
| Static Screen Contrast | 1000 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | |
| Screen Vertical Viewing Angle | 178 ° | |
| Display Minimum Response Time | 8 ms | |
| Display Coating | Anti-glare/Matte (3H) | |
| 3D | No | |
| Size, weight, color | Case Depth | 2.31 in 5.9 cm 58.6 mm 0.19 ft |
| Case Weight | 5.2 kg 11 lbs |
|
| Case Width with Stand | 21.9 in 55.6 cm 556.2 mm 1.82 ft |
|
| Case Height with Stand | 14.93 in 37.9 cm 379.1 mm 1.24 ft |
|
| Case Depth with Stand | 9.17 in 23.3 cm 233 mm 0.76 ft |
|
| Case Weight with Stand | 8 kg 18 lbs |
|
| Case Color | Black, White | |
| Hardware | Built-in Camera | No |
| Connectivity | 1 x HDMI 1.4 1 x DisplayPort 1.2 1 x D-sub 1 x 3.5 mm Audio Out 1 x 3.5 mm Audio In 1 x DVI-D Dual Link 2 x USB 2.0 (downstream) 2 x USB 2.0 (upstream) |
|
| Audio | Audio Speakers | 2 x 1W |
| Features | Cool Features | HDCP (High-bandwidth Digital Content Protection) Light sensor Picture-by-Picture XtraView+ Picture-in-Picture NaViSet software DisplaySync Pro EcoModes |
| Ergonomics | Case Width | 21.9 in 55.6 cm 556.2 mm 1.82 ft |
| Case Height | 14.24 in 36.2 cm 361.8 mm 1.19 ft |
|
| Vesa Mount Support | Yes | |
| VESA Interface Standard Size | 100 x 100 | |
| Removable VESA Stand | Yes | |
| Height Adjustment | Yes | |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
|
| Landscape or Portrait Pivot Support | Yes | |
| Left Pivot | 0 ° | |
| Right Pivot | 90 ° | |
| Left or Right Swivel Support | Yes | |
| Left Swivel | 170 ° | |
| Right Swivel | 170 ° | |
| Forward and Backward Tilt Support | Yes | |
| Forward Tilt | 5 ° | |
| Backward Tilt | 30 ° | |
| Frequency and Interpolation | Vertical Digital Frequency | 50 Hz - 85 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 118.4 kHz | |
| Power | 110V | 100 V - 120 V |
| 220V | 220 V - 240 V | |
| AC Frequency | 50 Hz - 60 Hz | |
| Electric Power in Amperes | 0.8 A | |
| Power Consumption When Device is Off | 0.3 W | |
| Average Power Consumption | 35 W | |
| Accessories | Extras | DisplayPort cable DisplayPort cable - mini-DP to DP USB upstream cable |
| Certificates and Standards | Licenses | CE ENERGY STAR 6.0 ErP FCC Class B ISO 9241-307 MPR III PCT/Gost RoHS TCO Certified Displays 6.0 TÜV/Ergonomics TÜV/GS UL/cUL |
| Usage and Storage Requirements | Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | |
| Internal Storage Temperature | -10 °C - 60 °C 14 °F - 140 °F |
|
| Internal Storage Humidity | 10 % - 85 % | |
| Max Operating Altitude | 5000 | |
| Max Storage Altitude | 12192 |
