| Brand | Samsung |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | TN |
| Refresh Rate | 75 Hz |
| Min Response Time | 5 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2014 |
| Brand | Samsung |
| Model Number | S22D390H |
| Alias | LS22D390HS/XK LS22D390HS/XY |
| Size | 22" (inches) |
| Panel | TN |
| Operating System | Custom OS (Android 6.0 Marshmallow) |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 21.5 in 54.6 cm 546 mm 1.79 ft |
| Screen Width | 18.77 in 47.7 cm 476.64 mm 1.56 ft |
| Screen Height | 10.56 in 26.8 cm 268.11 mm 0.88 ft |
| Display Type | TN |
| Display Bit Depth | 8 bits |
| Frame Rate Control | No |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.248 mm |
| Screen Pixel Density | 102 ppi |
| Screen-to-Body Ratio | 76.87 % |
| Backlight Source | W-LED |
| Rec.2020 | 70 |
| NTSC 1953 | 72 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 170 ° |
| Screen Vertical Viewing Angle | 160 ° |
| Screen Input Lag | 50 ms |
| Display Minimum Response Time | 5 ms |
| Display Coating | Anti-glare/Matte |
| HDR | HLG (Hybrid Log Gamma) HDR10 |
| 3D | No |
| Size, weight, color | |
| Case Depth | 3.22 in 8.2 cm 81.7 mm 0.27 ft |
| Case Weight | 2.95 kg 6 lbs |
| Case Width with Stand | 20.24 in 51.4 cm 514.2 mm 1.69 ft |
| Case Height with Stand | 15.8 in 40.1 cm 401.4 mm 1.32 ft |
| Case Depth with Stand | 7.28 in 18.5 cm 184.9 mm 0.61 ft |
| Case Weight with Stand | 3.2 kg 7 lbs |
| Case Color | Black |
| Hardware | |
| CPU Cores | 4 |
| RAM Memory Size | 1.5 |
| Internal Storage | 8 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T DVB-T2 DVB-C DVB-S DVB-S2 |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi Direct |
| Connectivity | 1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x D-sub |
| Audio | |
| Features | |
| OS | Custom OS (Android 6.0 Marshmallow) |
| Cool Features | Flicker-free technology Samsung MagicBright Samsung MagicUpscale Eco Saving Plus Eye Saver Mode |
| Ergonomics | |
| Case Width | 20.24 in 51.4 cm 514.2 mm 1.69 ft |
| Case Height | 12.73 in 32.3 cm 323.3 mm 1.06 ft |
| Vesa Mount Support | No |
| VESA Interface Standard Size | 75 x 75 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 1 ° |
| Backward Tilt | 20 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 56 Hz - 75 Hz |
| Horizontal Digital Frequency | 30 kHz - 81 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 21 W |
| Maximum Power Consumption | 760 W |
| Energy Class | B |
| Accessories | |
| Extras | D-sub cable |
| Certificates and Standards | |
| Licenses | CE ENERGY STAR 6.0 FCC class B |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 10 °C - 40 °C 50 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 80 % |
| Internal Storage Temperature | -20 °C - 45 °C -4 °F - 113 °F |
| Internal Storage Humidity | 5 % - 95 % |
