| Brand | LG |
| Type | TV |
| Size | 77" (inches) |
| Panel | OLED |
| Refresh Rate | 120 Hz |
| Min Response Time | 1 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2019 |
| Brand | LG |
| Model Series | W9 |
| Model Number | OLED77W9PLA |
| Size | 77" (inches) |
| Panel | OLED |
| Operating System | webOS 4.5 |
| Display | |
| Screen Size Class | 77" (inches) |
| Diagonal Size | 77.01 in 195.6 cm 1956 mm 6.42 ft |
| Screen Width | 67.12 in 170.5 cm 1704.8 mm 5.59 ft |
| Screen Height | 37.75 in 95.9 cm 958.951 mm 3.15 ft |
| Display Manufacturer | LG Display |
| Display Type | OLED |
| Display Bit Depth | 10 bits |
| Frame Rate Control | No |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.444 mm |
| Screen Pixel Density | 57 ppi |
| Screen-to-Body Ratio | 96.05 % |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 1 ms |
| HDR | Dolby Vision HDR10 HLG (Hybrid Log Gamma) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 0.23 in 0.6 cm 5.96 mm 0.02 ft |
| Case Color | Black |
| Hardware | |
| CPU Cores | 4 |
| GPU Cores | 2 |
| RAM Memory Size | 3 |
| Internal Storage | 8 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T DVB-T2 DVB-C DVB-S DVB-S2 |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi Direct DLNA Bluetooth 5.0 |
| Connectivity | 4 x HDMI 2.1 (eARC; CEC) 1 x Satellite In (Main; F-type female) 1 x Optical Audio Out 1 x CI+ 1.4 1 x Antenna (RF) (female) 1 x AV Composite In 3.5 mm jack 3 x USB 2.0 1 x Ethernet RJ45 |
| Audio | |
| Audio Speakers | 2 x 10W |
| Built-in Subwoofer | 2 x 10 |
| Features | |
| OS | webOS 4.5 |
| Cool Features | PVR Voice command ULTRA Luminance Pro 4K Upscaler Perfect Black Panel Oled Motion SIMPLINK (HDMI CEC) Picture-on-Wall Advanced Color Enhancer Image Processor - α9 Gen 2 Intelligent Processor Clear Voice III Google Assistant Object Depth Enhancer Infinite Contrast Pixel Level Dimming Frequency Based Sharpness Enhancer True Color Accuracy Pro Auto Low Latency Mode 4-step noise reduction LG ThinQ AI HDCP (High-bandwidth Digital Content Protection) 2.2 4K Cinema HDR HDR Dynamic Tone Mapping Pro |
| Ergonomics | |
| Case Width | 67.76 in 172.1 cm 1721 mm 5.65 ft |
| Case Height | 38.94 in 98.9 cm 989 mm 3.24 ft |
| Vesa Mount Support | No |
| VESA Interface Standard Size | 600 x 300 |
| Removable VESA Stand | No |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 120 Hz |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 210 W |
| Energy Class | A |
| Accessories | |
| Extras | 3.5 mm composite adapter Magic remote control - AN-MR19 |
| Certificates and Standards | |
| Licenses | ENERGY STAR RoHS UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 85 % |
