2022 77" Sony XR-77A80K Specifications

Brand Sony
Type TV
Size 77" (inches)
Panel OLED
Refresh Rate 120 Hz
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
General Info
Type TV
Year 2022
Brand Sony
Model Series A80K
Model Number XR-77A80K
Alias XR-77A83K
XR-77A84K
Size 77" (inches)
Panel OLED
Operating System Google TV (Android 11)
Display
Screen Size Class 77" (inches)
Diagonal Size 76.77 in
195 cm
1950 mm
6.4 ft
Screen Width 66.91 in
170 cm
1699.57 mm
5.58 ft
Screen Height 37.64 in
95.6 cm
956.009 mm
3.14 ft
Display Manufacturer LG Display
Display Type OLED
Display Bit Depth 10 bits
Frame Rate Control No
Max Number of Colors 1073741824
Bits 30
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
Screen Pixel Pitch 0.443 mm
Screen Pixel Density 57 ppi
Screen-to-Body Ratio 94.54 %
Screen Horizontal Viewing Angle 178 °
Screen Vertical Viewing Angle 178 °
HDR Dolby Vision
HDR10
HLG (Hybrid Log Gamma)
3D No
Size, weight, color
Case Depth 2.13 in
5.4 cm
54 mm
0.18 ft
Case Weight 34.8 kg
77 lbs
Case Width with Stand 67.8 in
172.2 cm
1722 mm
5.65 ft
Case Height with Stand 40.31 in
102.4 cm
1024 mm
3.36 ft
Case Depth with Stand 15.31 in
38.9 cm
389 mm
1.28 ft
Case Weight with Stand 37 kg
81 lbs
Case Color Titanium Black
Hardware
Internal Storage 16
TV Tuner Analog (NTSC/PAL/SECAM)
DVB-T
DVB-T2
DVB-C
DVB-S
DVB-S2
Built-in Camera No
Network LAN
Wi-Fi
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11n 5GHz
802.11ac (IEEE 802.11ac)
Wi-Fi Direct
DLNA
Bluetooth 4.2
Connectivity 2 x HDMI 2.0
2 x HDMI 2.1
1 x CI+ 1.4
1 x Satellite In (Sub; F-type female)
1 x Optical Audio Out
1 x AV Composite In 3.5 mm jack
1 x Satellite In (Main; F-type female)
2 x USB
1 x 3.5 mm Audio Out
1 x Ethernet RJ45
1 x Antenna (RF) (female)
Audio
Audio Speakers 3 x 10W
Built-in Subwoofer 2 x 10
Features
OS Google TV (Android 11)
Cool Features XR Smoothing
Voice command
XR Picture
XR OLED Contrast Pro
Apple HomeKit
Netflix Calibrated Mode
Live Color Technology
XR 4K Upscaling
Pixel Contrast Booster
Auto Calibration with CalMAN
XR Triluminos Pro
Dynamic Contrast Enhancer
Auto HDR Tone Mapping
Chromecast Built-in
Light Sensor
Google Assistant
Rich Color Enhancer (A83K and A84K only)
Bravia Core
XR OLED Motion
XR HDR Remaster
XR Super Resolution
Auto Genre Picture Mode
Alexa
IMAX Enhanced
Creator Calibrated Mode
Apple AirPlay
Dual Database Processing
Ergonomics
Case Width 67.8 in
172.2 cm
1722 mm
5.65 ft
Case Height 39.29 in
99.8 cm
998 mm
3.27 ft
Vesa Mount Support Yes
VESA Interface Standard Size 300 x 300
Removable VESA Stand Yes
Height Adjustment Yes
Height Adjustment Range 42 mm
4.2 cm
1.6535 in
0.1378 ft
Landscape or Portrait Pivot Support No
Left or Right Swivel Support No
Forward and Backward Tilt Support No
Frequency and Interpolation
Vertical Digital Frequency 40 Hz - 120 Hz
Screen Interpolation Measurement Unit NULL
Power
110V 100 V - 110 V
220V 220 V - 240 V
AC Frequency 50 Hz - 60 Hz
Power Consumption in Sleep Mode 0.5 W
Accessories
Extras Voice remote control
Certificates and Standards
Licenses ENERGY STAR
UL/cUL
Usage and Storage Requirements
Safe Operating Temperature Level 0 °C - 40 °C
32 °F - 104 °F
Safe Operating Humidity Level 10 % - 80 %
