| Brand | TCL |
| Type | TV |
| Size | 40" (inches) |
| Panel | VA |
| Refresh Rate | 60 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2018 |
| Brand | TCL |
| Model Series | S50 |
| Model Number | 40DS500 |
| Size | 40" (inches) |
| Panel | VA |
| Operating System | Smart TV.3 |
| Display | |
| Screen Size Class | 40" (inches) |
| Diagonal Size | 40 in 101.6 cm 1016 mm 3.33 ft |
| Screen Width | 34.86 in 88.6 cm 885.521 mm 2.91 ft |
| Screen Height | 19.61 in 49.8 cm 498.105 mm 1.63 ft |
| Display Type | VA |
| Display Bit Depth | 8 bits |
| Frame Rate Control | No |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.461 mm |
| Screen Pixel Density | 55 ppi |
| Screen-to-Body Ratio | 92.4 % |
| Backlight Source | Direct LED |
| Screen Brightness | 280 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.95 in 7.5 cm 75 mm 0.25 ft |
| Case Weight | 6.8 kg 15 lbs |
| Case Width with Stand | 35.87 in 91.1 cm 911 mm 2.99 ft |
| Case Height with Stand | 22.64 in 57.5 cm 575 mm 1.89 ft |
| Case Depth with Stand | 7.48 in 19 cm 190 mm 0.62 ft |
| Case Weight with Stand | 6.9 kg 15 lbs |
| Case Color | Black |
| Hardware | |
| CPU Cores | 2 |
| Internal Storage | 16 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) Wi-Fi Direct DLNA |
| Connectivity | 3 x HDMI 1.4 (ARC; CEC) 1 x Satellite In (Main; F-type female) 1 x AV Component In (YPbPr + L/R) 1 x 3.5 mm Audio Out 1 x S/PDIF 1 x AV Composite In (Video + L/R) 2 x USB 2.0 1 x Antenna (RF) (female) 1 x Ethernet RJ45 1 x CI+ |
| Audio | |
| Audio Speakers | 2 x 8W |
| Features | |
| OS | Smart TV.3 |
| Cool Features | Mega Dynamic Contrast Micro Dimming Picture Noise Reduction Color Extender HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Case Width | 35.87 in 91.1 cm 911 mm 2.99 ft |
| Case Height | 20.63 in 52.4 cm 524 mm 1.72 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index |
| Screen Interpolation Value | 400 |
| Screen Interpolation Measurement Unit | PPI |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.25 W |
| Average Power Consumption | 61 W |
| Maximum Power Consumption | 80 W |
| Energy Class | A++ |
| Accessories | |
| Extras | Remote control - RC802N2 |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
