| Brand | TCL |
| Type | TV |
| Size | 40" (inches) |
| Panel | VA |
| Refresh Rate | 60 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2017 |
| Brand | TCL |
| Model Series | S305 |
| Model Number | 40S305 |
| Size | 40" (inches) |
| Panel | VA |
| Operating System | Roku TV |
| Display | |
| Screen Size Class | 40" (inches) |
| Diagonal Size | 40 in 101.6 cm 1016 mm 3.33 ft |
| Screen Width | 34.86 in 88.6 cm 885.521 mm 2.91 ft |
| Screen Height | 19.61 in 49.8 cm 498.105 mm 1.63 ft |
| Display Type | VA |
| Display Bit Depth | 8 bits |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.461 mm |
| Screen Pixel Density | 55 ppi |
| Screen-to-Body Ratio | 89.26 % |
| Backlight Source | Direct LED |
| DCI P3 | 80% |
| Rec.2020 | 59 |
| Screen Brightness | 200 cd/m² |
| Static Screen Contrast | 3500 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Screen Input Lag | 29 ms |
| Display Average Response Time | 14 ms |
| Display Maximum Response Time | 20 ms |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.9 in 7.4 cm 73.66 mm 0.24 ft |
| Case Weight | 6.5 kg 14 lbs |
| Case Width with Stand | 36.3 in 92.2 cm 922 mm 3.02 ft |
| Case Height with Stand | 23.4 in 59.4 cm 594.36 mm 1.95 ft |
| Case Depth with Stand | 7.8 in 19.8 cm 198.1 mm 0.65 ft |
| Case Weight with Stand | 6.6 kg 15 lbs |
| Case Color | Black |
| Hardware | |
| TV Tuner | Analog (NTSC/PAL/SECAM) Clear QAM ATSC |
| Built-in Camera | No |
| Network | Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz |
| Connectivity | 1 x Satellite In (Main; F-type female) 1 x AV Composite In (Video + L/R) 1 x 3.5 mm Audio Out 1 x S/PDIF 1 x USB 2.0 (max 0.5 A) 3 x HDMI 1.4 (ARC; CEC) |
| Audio | |
| Audio Speakers | 2 x 4W |
| Features | |
| OS | Roku TV |
| Cool Features | HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Case Width | 36.3 in 92.2 cm 922 mm 3.02 ft |
| Case Height | 21.1 in 53.6 cm 535.94 mm 1.76 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Clear Motion Index |
| Screen Interpolation Value | 120 |
| Screen Interpolation Measurement Unit | CMI |
| Power | |
| 110V | 100 V - 120 V |
| AC Frequency | 50 Hz - 60 Hz |
| Average Power Consumption | 60 W |
| Power Consumption in Eco Mode | 40 W |
| Accessories | |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
