| Brand | TCL |
| Type | TV |
| Size | 43" (inches) |
| Panel | VA |
| Refresh Rate | 60 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2019 |
| Brand | TCL |
| Model Series | EP66 |
| Model Number | 43EP660 |
| Size | 43" (inches) |
| Panel | VA |
| Operating System | Android 9.0 Pie |
| Display | |
| Screen Size Class | 43" (inches) |
| Diagonal Size | 42.52 in 108 cm 1080 mm 3.54 ft |
| Screen Width | 37.05 in 94.1 cm 941.184 mm 3.09 ft |
| Screen Height | 20.84 in 52.9 cm 529.416 mm 1.74 ft |
| Display Type | VA |
| Display Bit Depth | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.245 mm |
| Screen Pixel Density | 103 ppi |
| Screen-to-Body Ratio | 89.81 % |
| Backlight Source | Direct LED |
| Screen Brightness | 290 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| HDR | HDR10 HLG (Hybrid Log Gamma) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 3.07 in 7.8 cm 78 mm 0.26 ft |
| Case Weight | 7.5 kg 17 lbs |
| Case Width with Stand | 38.19 in 97 cm 970 mm 3.18 ft |
| Case Height with Stand | 24.69 in 62.7 cm 627 mm 2.06 ft |
| Case Depth with Stand | 8.74 in 22.2 cm 222 mm 0.73 ft |
| Case Weight with Stand | 7.6 kg 17 lbs |
| Case Color | Black |
| Hardware | |
| CPU Cores | 4 |
| Internal Storage | 16 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 2 x HDMI 2.0 (ARC; CEC; MHL) 1 x Satellite In (Main; F-type female) 1 x S/PDIF 1 x Antenna (RF) (female) 1 x 3.5 mm Audio Out 1 x AV Composite In (Video + L/R) 1 x USB 2.0 1 x CI+ 1 x Ethernet RJ45 |
| Audio | |
| Audio Speakers | 2 x 8W |
| Features | |
| OS | Android 9.0 Pie |
| Cool Features | IPQ Engine Mega Dynamic Contrast Picture-in-Picture UHD Upscaling UHD Color Extender Noise Reduction Dimming Pro Wide Color Gamut HDCP (High-bandwidth Digital Content Protection) 2.2 |
| Ergonomics | |
| Case Width | 38.19 in 97 cm 970 mm 3.18 ft |
| Case Height | 22.52 in 57.2 cm 572 mm 1.88 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index |
| Screen Interpolation Value | 1200 |
| Screen Interpolation Measurement Unit | PPI |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.28 W |
| Power Consumption in Sleep Mode | 0.77 W |
| Average Power Consumption | 70 W |
| Maximum Power Consumption | 100 W |
| Energy Class | A |
| Accessories | |
| Extras | Remote control - RC802N6 |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
