| Brand | TCL |
| Type | TV |
| Size | 65" (inches) |
| Panel | VA |
| Refresh Rate | 60 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2018 |
| Brand | TCL |
| Model Series | P66 |
| Model Number | 65DP660 |
| Alias | 65DP661 |
| Size | 65" (inches) |
| Panel | VA |
| Operating System | Android 7.0 Nougat Android 8.0 Oreo |
| Display | |
| Screen Size Class | 65" (inches) |
| Diagonal Size | 64.53 in 163.9 cm 1639 mm 5.38 ft |
| Screen Width | 56.24 in 142.8 cm 1428.48 mm 4.69 ft |
| Screen Height | 31.63 in 80.4 cm 803.52 mm 2.64 ft |
| Display Type | VA |
| Display Bit Depth | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.372 mm |
| Screen Pixel Density | 68 ppi |
| Screen-to-Body Ratio | 94.17 % |
| Backlight Source | Edge LED |
| DCI P3 | 94% |
| Screen Brightness | 270 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| HDR | HDR10 HLG (Hybrid Log Gamma) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.83 in 7.2 cm 72 mm 0.24 ft |
| Case Weight | 21.8 kg 48 lbs |
| Case Width with Stand | 57.13 in 145.1 cm 1451 mm 4.76 ft |
| Case Height with Stand | 35 in 88.9 cm 889 mm 2.92 ft |
| Case Depth with Stand | 10.55 in 26.8 cm 268 mm 0.88 ft |
| Case Weight with Stand | 22 kg 48 lbs |
| Case Color | Silver |
| Hardware | |
| CPU Cores | 4 |
| Internal Storage | 16 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 1 x Ethernet RJ45 3 x HDMI 2.0 (ARC; CEC; MHL) 1 x Video Component In 3.5 mm jack 1 x 3.5 mm Audio Out 1 x S/PDIF 1 x Satellite In (Main; F-type female) 1 x USB 2.0 1 x Antenna (RF) (female) 1 x USB 3.0 1 x CI+ |
| Audio | |
| Audio Speakers | 2 x 8W |
| Features | |
| OS | Android 7.0 Nougat Android 8.0 Oreo |
| Cool Features | Micro Dimming Picture Noise Reduction Smart HDR UHD Upscaling UHD Premium Color Extender Pure Image Ultra HD HDCP (High-bandwidth Digital Content Protection) 2.2 Wide Color Gamut Mega Dynamic Contrast |
| Ergonomics | |
| Case Width | 57.13 in 145.1 cm 1451 mm 4.76 ft |
| Case Height | 33.07 in 84 cm 840 mm 2.76 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 400 x 200 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index |
| Screen Interpolation Value | 1500 |
| Screen Interpolation Measurement Unit | PPI |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.29 W |
| Average Power Consumption | 118 W |
| Maximum Power Consumption | 150 W |
| Energy Class | A+ |
| Accessories | |
| Extras | Remote control - RC802N1 |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
