| Brand | TCL |
| Type | TV |
| Size | 55" (inches) |
| Panel | SVA |
| Refresh Rate | 60 Hz |
| Min Response Time | 8 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | Type | TV |
|---|---|---|
| Year | 2017 | |
| Brand | TCL | |
| Model Series | C70 | |
| Model Number | U55C7006 | |
| Size | 55" (inches) | |
| Panel | SVA | |
| Operating System | Android 6.0.1 Marshmallow | |
| Display | Screen Size Class | 55" (inches) |
| Diagonal Size | 54.65 in 138.8 cm 1388 mm 4.55 ft |
|
| Screen Width | 47.62 in 121 cm 1209.6 mm 3.97 ft |
|
| Screen Height | 26.79 in 68 cm 680.4 mm 2.23 ft |
|
| Display Manufacturer | Samsung | |
| Display Type | SVA | |
| Display Bit Depth | 10 bits (8 bits + FRC) | |
| Frame Rate Control | Yes | |
| Max Number of Colors | 1073741824 | |
| Bits | 30 | |
| Screen Aspect Ratio | 16:9 | |
| Screen Resolution | 3840 x 2160 | |
| Screen Pixel Pitch | 0.315 mm | |
| Screen Pixel Density | 80 ppi | |
| Screen-to-Body Ratio | 91.96 % | |
| Backlight Source | Edge LED | |
| DCI P3 | 83% | |
| Rec.2020 | 60 | |
| sRGB | 99 % | |
| Screen Brightness | 350 cd/m² | |
| Max Screen Brightness | 450 cd/m² | |
| Static Screen Contrast | 3500 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | |
| Screen Vertical Viewing Angle | 178 ° | |
| Screen Input Lag | 26 ms | |
| Display Minimum Response Time | 8 ms | |
| HDR | HDR10 HLG (Hybrid Log Gamma) |
|
| 3D | No | |
| Size, weight, color | Case Depth | 2.17 in 5.5 cm 55 mm 0.18 ft |
| Case Weight | 16.4 kg 36 lbs |
|
| Case Width with Stand | 48.94 in 124.3 cm 1243 mm 4.08 ft |
|
| Case Height with Stand | 29.72 in 75.5 cm 755 mm 2.48 ft |
|
| Case Depth with Stand | 8.62 in 21.9 cm 219 mm 0.72 ft |
|
| Case Weight with Stand | 16.8 kg 37 lbs |
|
| Case Color | Black | |
| Hardware | System on Chip or SoC | Mediatek MT5891 |
| CPU | ARM Cortex-A53 | |
| CPU Cores | 4 | |
| CPU Frequency | 1100 | |
| GPU | ARM Mali-T860 MP2 | |
| GPU Cores | 2 | |
| GPU Frequency | 700 | |
| RAM Memory Size | 2 | |
| Internal Storage | 16 | |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
|
| Built-in Camera | No | |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11ac (IEEE 802.11ac) Bluetooth Wi-Fi Direct DLNA |
|
| Connectivity | 1 x Ethernet RJ45 3 x HDMI 2.0 (ARC; CEC; MHL) 1 x S/PDIF 1 x Antenna (RF) (female) 1 x 3.5 mm Audio Out 1 x Satellite In (Main; F-type female) 1 x USB 2.0 1 x CI+ 1 x USB 3.0 (max 1 A) |
|
| Audio | Audio Speakers | 2 x 12W |
| Features | OS | Android 6.0.1 Marshmallow |
| Cool Features | Picture Noise Reduction UHD Premium Color Extender Voice command Wide Color Gamut UHD Upscaling HDCP (High-bandwidth Digital Content Protection) 2.2 Mega Dynamic Contrast |
|
| Ergonomics | Case Width | 48.94 in 124.3 cm 1243 mm 4.08 ft |
| Case Height | 28.35 in 72 cm 720 mm 2.36 ft |
|
| Vesa Mount Support | Yes | |
| VESA Interface Standard Size | 200 x 200 | |
| Removable VESA Stand | Yes | |
| Height Adjustment | No | |
| Landscape or Portrait Pivot Support | No | |
| Left or Right Swivel Support | No | |
| Forward and Backward Tilt Support | No | |
| Frequency and Interpolation | Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index | |
| Screen Interpolation Value | 1600 | |
| Screen Interpolation Measurement Unit | PPI | |
| Power | 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz | |
| Power Consumption When Device is Off | 0.29 W | |
| Average Power Consumption | 120 W | |
| Power Consumption in Eco Mode | 87 W | |
| Maximum Power Consumption | 140 W | |
| Energy Class | A+ | |
| Accessories | Extras | Remote control - RC802N1 |
| Certificates and Standards | Licenses | RoHS |
| Usage and Storage Requirements | Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % | |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
|
| Internal Storage Humidity | 10 % - 90 % |
