| Brand | TCL |
| Type | TV |
| Size | 55" (inches) |
| Panel | VA |
| Refresh Rate | 0 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2016 |
| Brand | TCL |
| Model Series | S69 |
| Model Number | U55S6906 |
| Size | 55" (inches) |
| Panel | VA |
| Operating System | Smart TV.2 |
| Display | |
| Screen Size Class | 55" (inches) |
| Diagonal Size | 54.65 in 138.8 cm 1388 mm 4.55 ft |
| Screen Width | 47.62 in 121 cm 1209.6 mm 3.97 ft |
| Screen Height | 26.79 in 68 cm 680.4 mm 2.23 ft |
| Display Type | VA |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.315 mm |
| Screen Pixel Density | 80 ppi |
| Screen-to-Body Ratio | 91.76 % |
| Backlight Source | Direct LED |
| Screen Brightness | 370 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| 3D | No |
| Size, weight, color | |
| Case Depth | 3.15 in 8 cm 80 mm 0.26 ft |
| Case Weight | 15.4 kg 34 lbs |
| Case Width with Stand | 48.98 in 124.4 cm 1244 mm 4.08 ft |
| Case Height with Stand | 30.47 in 77.4 cm 774 mm 2.54 ft |
| Case Depth with Stand | 8.46 in 21.5 cm 215 mm 0.71 ft |
| Case Weight with Stand | 15.5 kg 34 lbs |
| Case Color | Black |
| Hardware | |
| CPU Cores | 4 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11ac (IEEE 802.11ac) Wi-Fi Direct DLNA |
| Connectivity | 1 x Ethernet RJ45 4 x HDMI 2.0 (ARC; CEC; MHL) 1 x CI+ 1.3 1 x SCART 1 x S/PDIF 1 x AV Component In (YPbPr + L/R) 1 x Satellite In (Main; F-type female) 1 x USB 2.0 1 x 3.5 mm Audio Out 1 x USB 3.0 (max 1 A) 1 x Antenna (RF) (female) |
| Audio | |
| Audio Speakers | 2 x 10W |
| Features | |
| OS | Smart TV.2 |
| Cool Features | Mega Dynamic Contrast Picture Noise Reduction Super Resolution EX Pure Image Ultra HD Digital Pure Sound HDCP (High-bandwidth Digital Content Protection) 2.2 |
| Ergonomics | |
| Case Width | 48.98 in 124.4 cm 1244 mm 4.08 ft |
| Case Height | 28.39 in 72.1 cm 721 mm 2.37 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 200 x 200 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Screen Interpolation Technology | Picture Performance Index |
| Screen Interpolation Value | 800 |
| Screen Interpolation Measurement Unit | PPI |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.29 W |
| Average Power Consumption | 85 W |
| Power Consumption in Eco Mode | 74 W |
| Maximum Power Consumption | 130 W |
| Energy Class | A+ |
| Accessories | |
| Extras | Remote control - RC311 |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
