| Brand | TCL |
| Type | TV |
| Size | 60" (inches) |
| Panel | IPS, VA |
| Refresh Rate | 60 Hz |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2017 |
| Brand | TCL |
| Model Number | U60V6026 |
| Size | 60" (inches) |
| Panel | IPS, VA |
| Operating System | Smart TV |
| Display | |
| Screen Size Class | 60" (inches) |
| Diagonal Size | 59.49 in 151.1 cm 1511 mm 4.96 ft |
| Screen Width | 52.38 in 133.1 cm 1330.56 mm 4.37 ft |
| Screen Height | 29.47 in 74.8 cm 748.44 mm 2.46 ft |
| Display Type | IPS, VA |
| Display Bit Depth | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.347 mm |
| Screen Pixel Density | 73 ppi |
| Screen-to-Body Ratio | 94.09 % |
| Backlight Source | Direct LED |
| Screen Brightness | 360 cd/m² |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| HDR | HDR10 HLG (Hybrid Log Gamma) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 3.03 in 7.7 cm 77 mm 0.25 ft |
| Case Weight | 16 kg 35 lbs |
| Case Width with Stand | 53.15 in 135 cm 1350 mm 4.43 ft |
| Case Height with Stand | 33.27 in 84.5 cm 845 mm 2.77 ft |
| Case Depth with Stand | 9.57 in 24.3 cm 243 mm 0.8 ft |
| Case Weight with Stand | 16.3 kg 36 lbs |
| Case Color | Black, Gray |
| Hardware | |
| CPU Cores | 2 |
| RAM Memory Size | 2 |
| Internal Storage | 16 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T2 DVB-S2 DVB-C DVB-T DVB-S |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11ac (IEEE 802.11ac) Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 3 x HDMI 2.0 (ARC; CEC; MHL) 1 x Satellite In (Main; F-type female) 1 x AV Component In (YPbPr + L/R) 1 x 3.5 mm Audio Out 1 x S/PDIF 1 x AV Composite In (Video + L/R) 2 x USB 2.0 1 x Antenna (RF) (female) 1 x Ethernet RJ45 1 x CI+ |
| Audio | |
| Audio Speakers | 2 x 8W |
| Features | |
| OS | Smart TV |
| Cool Features | Picture Noise Reduction Pure Image Ultra HD UHD Color Extender Super Resolution EX HDCP (High-bandwidth Digital Content Protection) 2.2 Micro Dimming Pro |
| Ergonomics | |
| Case Width | 53.15 in 135 cm 1350 mm 4.43 ft |
| Case Height | 30.87 in 78.4 cm 784 mm 2.57 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 200 x 300 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Performance Index |
| Screen Interpolation Value | 1200 |
| Screen Interpolation Measurement Unit | PPI |
| Power | |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.29 W |
| Average Power Consumption | 132 W |
| Maximum Power Consumption | 150 W |
| Energy Class | A |
| Accessories | |
| Extras | Remote control - RC802N |
| Certificates and Standards | |
| Licenses | RoHS |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -15 °C - 45 °C 5 °F - 113 °F |
| Internal Storage Humidity | 10 % - 90 % |
